Tool Setter m&h TS35.20

Take Your Production to a New Level with the TIGO SF

Developed for the shop-floor, the TIGO SF is a fully-protected and versatile coordinate measuring machine (CMM) that combines robust construction, innovative technology and flexibility of setup to ensure high-accuracy measurement in the harshest of environments.

Training and Resources

Tool Setter m&h TS35.20 Specifications

Accuracy	Triggering force	Temperature range	Power supply
1μm (max. 2 Sigma)	X/Y = 0,5 - 1,1 N; Z = 5 N	Operation: 10°C -50°C, Storage: 5°C -70°C	Battery 12 - 32 VDC, max 25mA with a cable
Protection class	Signal transmission
IP68: EN60529	Cable

Accuracy

Triggering force

Temperature range

Power supply

1μm (max. 2 Sigma)

X/Y = 0,5 - 1,1 N; Z = 5 N

Operation: 10°C -50°C,

Storage: 5°C -70°C

Battery 12 - 32 VDC, max 25mA with a cable

Protection class

Signal transmission

IP68: EN60529

Cable

Accuracy
1μm (max. 2 Sigma)
Triggering force
X/Y = 0,5 - 1,1 N; Z = 5 N
Temperature range
Operation: 10°C -50°C, Storage: 5°C -70°C
Power supply
Battery 12 - 32 VDC, max 25mA with a cable
Protection class
IP68: EN60529
Signal transmission
Cable
