Alignments
· You can now see correct results when you copy or serialize a measured circle feature with a referenced plane feature. See PCD-234022.
Application
· PC-DMIS now saves the JSON file to the correct version directory when you save or edit an environment. See PCD-264427.
· PC-DMIS now checks for information to populate dialogs with features more quickly, resulting in improved execution speed. See PCD-264357.
· You can now see that numerous application errors based on crash reports have been fixed, and protection for various exceptions (crashes) has been added to improve product stability. See PCD-268625.
Application Errors
You no longer get application errors:
· When you use an expression as an input for a looped best fit alignment. See PCD-268258.
· When you scan with an AS1-XL laser sensor on a Romer Arm. See PCD-269941.
Auto Features (Tactile)
· PC-DMIS no longer displays the Nexus login dialog box when you click Test on the Auto Feature dialog box. See PCD-259619.
CAD
· PC-DMIS now removes only the selected CAD component from the Graphic Display window when you delete it from the Assembly Tree View in the CAD Assembly dialog box. See PCD-267705.
· PC-DMIS now correctly reports collisions when you import a DCI CATIA file and the measurement routine is created in inches. See PCD-269179.
Constructed Extracted Features
· PC-DMIS now correctly evaluates Constructed Extracted Surfaces even when very close opposite surfaces are present. See PCD-269202.
Constructed Features
· PC-DMIS now populates the Feature list area of the Construct Cylinder dialog box more quickly. See PCD-270031.
ESF (VWMP)
· PC-DMIS now correctly displays the T deviation in the Probe Readouts window for all ESF feature types, including those measured with Arm2. See PCD-269257.
GD&T Dimensions
· PC-DMIS no longer resets to the default planar tolerance zone when you delete a Geometric Tolerance command and then undo the action. See PCD-256286.
· You can now see singular datum definitions in the drop-down menu of the Feature Control Frame Editor in the Feature Control Frame tab of the Geometric Tolerance dialog box. See PCD-260706.
· PC-DMIS no longer displays the plane outlines in the Graphic Display window when you turn off the CADGRAPH option for a Runout tolerance. See PCD-265875.
· You can no longer update Geometric Tolerance commands using Ctrl+A and Ctrl+C keyboard shortcuts. See PCD-267864.
· PC-DMIS now removes all features from the Geometric Tolerance command when you remove the common datum from the Feature Control Frame tab of the Geometric Tolerance dialog box. See PCD-269154.
Home Page
· You can now see that measurement routines that are saved to network paths are now available in the Recent section of the PC-DMIS Home Page. See PCD-267153.
Reporting
· PC-DMIS now saves the edited CAD view orientation in a custom report. See PCD-267234.
· PC-DMIS now correctly stores the colormap active status in a viewset even when the colormap has no annotations. See PCD-268431.
· PC-DMIS no longer changes the geometric polar angle and measured axes deviations in a PDF report when the cursor is placed after the workplane command. See PCD-268781.
