Paste with pattern not working properly for constructed line

Hello everyone,
I'm working on a program with 2021.1 in which, it's been observed when using paste with pattern line created using a circle and a point is not generating properly.
upon pasting with pattern new lines generated doesn't includes circle leading to math error on execution...
what can be done to overcome this?

DAN_M over 2 years ago

Did you try writing the program using Mitutoyo, Camio, or Quartis?
Cancel
Vote Up 0 Vote Down

Sign in to reply

Cancel
bfire85 over 2 years ago

Please!!!!!!!
Cancel
Vote Up 0 Vote Down

Sign in to reply

Cancel
jigars over 2 years ago in reply to DAN_M

I have only used PCDMIS
one demon is enough for me lol
Cancel
Vote Up 0 Vote Down

Sign in to reply

Cancel
jigars over 2 years ago

generated by using patern:

LOC_LIN1_S5=FEAT/LINE,CARTESIAN,UNBOUNDED,NO
THEO/<0,0,-2.361>,<-0.0378415,0.9992838,0>
ACTL/<0,0,-2.361>,<-0.0378415,0.9992838,0>
CONSTR/LINE,BF,2D,LOC_PT3_S5,,
OUTLIER_REMOVAL/OFF,3
FILTER/OFF,WAVELENGTH=0

should be :

LOC_LIN1_S5=FEAT/LINE,CARTESIAN,UNBOUNDED,NO
THEO/<0,0,-2.361>,<-0.0378415,0.9992838,0>
ACTL/<0,0,-2.361>,<-0.0378415,0.9992838,0>
CONSTR/LINE,BF,2D,DATUM_B,LOC_PT3_S5,,
OUTLIER_REMOVAL/OFF,3
FILTER/OFF,WAVELENGTH=0
Cancel
Vote Up 0 Vote Down

Sign in to reply

Cancel
bfire85 over 2 years ago

generated by using patern:

LOC_LIN1_S5=FEAT/LINE,CARTESIAN,UNBOUNDED,NO
THEO/<0,0,-2.361>,<-0.0378415,0.9992838,0>
ACTL/<0,0,-2.361>,<-0.0378415,0.9992838,0>
CONSTR/LINE,BF,2D,LOC_PT3_S5,,
OUTLIER_REMOVAL/OFF,3
FILTER/OFF,WAVELENGTH=0

should be :

LOC_LIN1_S5=FEAT/LINE,CARTESIAN,UNBOUNDED,NO
THEO/<0,0,-2.361>,<-0.0378415,0.9992838,0>
ACTL/<0,0,-2.361>,<-0.0378415,0.9992838,0>
CONSTR/LINE,BF,2D,DATUM_B,LOC_PT3_S5,,
OUTLIER_REMOVAL/OFF,3
FILTER/OFF,WAVELENGTH=0

Oh I have seen that happen. I am not sure why it happens though. It's been a long time since I've ran into that issue.
Cancel
Vote Up 0 Vote Down

Sign in to reply

Cancel
jigars over 2 years ago

Oh I have seen that happen. I am not sure why it happens though. It's been a long time since I've ran into that issue.

might be some issue with software version
Cancel
Vote Up 0 Vote Down

Sign in to reply

Cancel
vpt.se over 2 years ago

File it as a bug.
Cancel
Vote Up 0 Vote Down

Sign in to reply

Cancel
SABarber over 2 years ago

There was a report filed (PCD-227893) constructed feature loses input feature upon patterning
This has been fixed in various service packs (2021.1SP10 and up).

The copying of the command would be enough to lose the input feature. I think just a plain copy/paste would exhibit the same issue.
Cancel
Vote Up 0 Vote Down

Sign in to reply

Cancel
bfire85 over 2 years ago

There was a report filed (PCD-227893) constructed feature loses input feature upon patterning
This has been fixed in various service packs (2021.1SP10 and up).

The copying of the command would be enough to lose the input feature. I think just a plain copy/paste would exhibit the same issue.

2021.1 SP10 is not available for release yet...as of now.
Cancel
Vote Up 0 Vote Down

Sign in to reply

Cancel
R2ah1ze1l over 2 years ago

As of 2020R2, if we do a 'select all' and copy the code, paste it to another program or to a document file, the constructions drop a feature. Often times we find it is something to the effect of point2 to point1 for a line construction, after the copy event the point2 gets dropped from the line construction. It has been quite irritating but we have found a pattern to help reduce it's impact.
