Unknown Move Point Deviation

Let me preface that I'm very new to programming, as well as, operating the CMM. So something that might seem like a obvious solution to most of you is like finding a needle in a hay stack for me, haha. Thanks!
While writing a program for a part, I have run into an issue with the probes movement. You can see, in the image above, that there is a line moving out of frame to the cylinder highlighted. I have been taught to prevent unintentional contact leading to a system crash to add a move point as seen (or use clearance planes/cube). The move point line should move all the way to the probe (indicated by the arrow), but instead stops at the question mark then deviates downwards and along the x-axis the then back towards the cylinder. The path then collides with the structure (indicated by the yellow X) and we cant be having that. My question is why? Why is it just randomly pivoting like this?
0 WilliamL 2 months ago in reply to ArkansasBeeper

Makes me wonder if there are any freaks out there that use Dmis mode.
Cancel
Vote Up 0 Vote Down

Sign in to reply

Verify Answer

Cancel
0 Brian Enz 2 months ago in reply to ArkansasBeeper

Hahaha, guilty as charged! I generally use summary mode.
Cancel
Vote Up 0 Vote Down

Sign in to reply

Verify Answer

Cancel
0 Brian Enz 2 months ago in reply to ArkansasBeeper
             ,SET WARNING LIMIT = FALSE,MINIMUM = 10,MAXIMUM = 40
              ,PART SENSOR NUM=DEFAULT,X SCALE= 20,Y SCALE= 20,Z SCALE= 20,PART TEMP=20
            MOVESPEED/ 250
            TOUCHSPEED/ 2
            PREHIT/0.2
            CHECK/0.3,1
            RETRACT/0.2
READPOINT  =FEAT/POINT,CARTESIAN
            THEO/<1.1491,0.1249,1.155>,<0,0,1>
            ACTL/<1.1491,0.1249,1.155>,<0,0,1>
            READPOINT/
            MODE/DCC
A1         =ALIGNMENT/START,RECALL:STARTUP,LIST=YES
              ALIGNMENT/TRANS,XAXIS,READPOINT
              ALIGNMENT/TRANS_OFFSET,XAXIS,-1.1491
              ALIGNMENT/TRANS,YAXIS,READPOINT
              ALIGNMENT/TRANS_OFFSET,YAXIS,-0.1249
              ALIGNMENT/TRANS,ZAXIS,READPOINT
              ALIGNMENT/TRANS_OFFSET,ZAXIS,-1.155
            ALIGNMENT/END
            MOVE/POINT,NORMAL,<0.2166,-2.0445,2>
            TIP/T1A-10B0, SHANKIJK=0, -0.1736, 0.9848, ANGLE=0
            WORKPLANE/YMINUS
PLNC VECTOR POINTS=GROUP/SHOWALLPARAMS=YES
PNT1         =FEAT/CONTACT/VECTOR POINT/DEFAULT,POLAR
              THEO/<0.9864,77.3168,0>,<0,-1,0>
              ACTL/<0.9864,77.3168,0>,<0,-1,0>
              TARG/<0.9864,77.3168,0>,<0,-1,0>
              SNAP=NO
              SHOW FEATURE PARAMETERS=NO
              SHOW CONTACT PARAMETERS=YES
                AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              SHOW HITS=NO
PNT2         =FEAT/CONTACT/VECTOR POINT/DEFAULT,POLAR
              THEO/<0.3091,45.4103,0>,<0,-1,0>
              ACTL/<0.3091,45.4103,0>,<0,-1,0>
              TARG/<0.3091,45.4103,0>,<0,-1,0>
              SNAP=NO
              SHOW FEATURE PARAMETERS=NO
              SHOW CONTACT PARAMETERS=YES
                AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              SHOW HITS=NO
PNT3         =FEAT/CONTACT/VECTOR POINT/DEFAULT,POLAR
              THEO/<3.9353,2.8347,0>,<0,-1,0>
              ACTL/<3.9353,2.8347,0>,<0,-1,0>
              TARG/<3.9353,2.8347,0>,<0,-1,0>
              SNAP=NO
              SHOW FEATURE PARAMETERS=NO
              SHOW CONTACT PARAMETERS=YES
                AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              SHOW HITS=NO
PNT4         =FEAT/CONTACT/VECTOR POINT/DEFAULT,POLAR
              THEO/<4.0503,14.3909,0>,<0,-1,0>
              ACTL/<4.0503,14.3909,0>,<0,-1,0>
              TARG/<4.0503,14.3909,0>,<0,-1,0>
              SNAP=NO
              SHOW FEATURE PARAMETERS=NO
              SHOW CONTACT PARAMETERS=YES
                AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              SHOW HITS=NO
PNT5         =FEAT/CONTACT/VECTOR POINT/DEFAULT,POLAR
              THEO/<8.1976,1.279,0>,<0,-1,0>
              ACTL/<8.1976,1.279,0>,<0,-1,0>
              TARG/<8.1976,1.279,0>,<0,-1,0>
              SNAP=NO
              SHOW FEATURE PARAMETERS=NO
              SHOW CONTACT PARAMETERS=YES
                AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              SHOW HITS=NO
PNT6         =FEAT/CONTACT/VECTOR POINT/DEFAULT,POLAR
              THEO/<8.108,7.4369,0>,<0,-1,0>
              ACTL/<8.108,7.4369,0>,<0,-1,0>
              TARG/<8.108,7.4369,0>,<0,-1,0>
              SNAP=NO
              SHOW FEATURE PARAMETERS=NO
              SHOW CONTACT PARAMETERS=YES
                AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              SHOW HITS=NO
PNT7         =FEAT/CONTACT/VECTOR POINT/DEFAULT,POLAR
              THEO/<11.7275,5.1391,0>,<0,-1,0>
              ACTL/<11.7275,5.1391,0>,<0,-1,0>
              TARG/<11.7275,5.1391,0>,<0,-1,0>
              SNAP=NO
              SHOW FEATURE PARAMETERS=NO
              SHOW CONTACT PARAMETERS=YES
                AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              SHOW HITS=NO
PNT8         =FEAT/CONTACT/VECTOR POINT/DEFAULT,POLAR
              THEO/<12.0839,0.8217,0>,<0,-1,0>
              ACTL/<12.0839,0.8217,0>,<0,-1,0>
              TARG/<12.0839,0.8217,0>,<0,-1,0>
              SNAP=NO
              SHOW FEATURE PARAMETERS=NO
              SHOW CONTACT PARAMETERS=YES
                AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              SHOW HITS=NO
PNT9         =FEAT/CONTACT/VECTOR POINT/DEFAULT,POLAR
              THEO/<16.5842,0.7549,0>,<0,-1,0>
              ACTL/<16.5842,0.7549,0>,<0,-1,0>
              TARG/<16.5842,0.7549,0>,<0,-1,0>
              SNAP=NO
              SHOW FEATURE PARAMETERS=NO
              SHOW CONTACT PARAMETERS=YES
                AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              SHOW HITS=NO
PNT10        =FEAT/CONTACT/VECTOR POINT/DEFAULT,POLAR
              THEO/<16.5632,3.4367,0>,<0,-1,0>
              ACTL/<16.5632,3.4367,0>,<0,-1,0>
              TARG/<16.5632,3.4367,0>,<0,-1,0>
              SNAP=NO
              SHOW FEATURE PARAMETERS=NO
              SHOW CONTACT PARAMETERS=YES
                AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              SHOW HITS=NO
PNT11        =FEAT/CONTACT/VECTOR POINT/DEFAULT,POLAR
              THEO/<22.5614,2.4764,0>,<0,-1,0>
              ACTL/<22.5614,2.4764,0>,<0,-1,0>
              TARG/<22.5614,2.4764,0>,<0,-1,0>
              SNAP=NO
              SHOW FEATURE PARAMETERS=NO
              SHOW CONTACT PARAMETERS=YES
                AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              SHOW HITS=NO
              MOVE/POINT,NORMAL,<22.5,-0.2296,2>
              MOVE/POINT,NORMAL,<24,-0.2296,2>
PNT12        =FEAT/CONTACT/VECTOR POINT/DEFAULT,POLAR
              THEO/<25.5378,1.2829,0>,<0,-1,0>
              ACTL/<25.5378,1.2829,0>,<0,-1,0>
              TARG/<25.5378,1.2829,0>,<0,-1,0>
              SNAP=NO
              SHOW FEATURE PARAMETERS=NO
              SHOW CONTACT PARAMETERS=YES
                AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              SHOW HITS=NO
PNT13        =FEAT/CONTACT/VECTOR POINT/DEFAULT,POLAR
              THEO/<25.8009,0.4669,0>,<0,-1,0>
              ACTL/<25.8009,0.4669,0>,<0,-1,0>
              TARG/<25.8009,0.4669,0>,<0,-1,0>
              SNAP=NO
              SHOW FEATURE PARAMETERS=NO
              SHOW CONTACT PARAMETERS=YES
                AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              SHOW HITS=NO
            ENDGROUP/ID=PLNC VECTOR POINTS
PLNC       =FEAT/PLANE,CARTESIAN,OUTLINE,NO,LEAST_SQR
            THEO/<11.9441,0,0.6006>,<0,-1,0>
            ACTL/<11.9441,0,0.6006>,<0,-1,0>
            CONSTR/PLANE,BF,PNT1,PNT2,PNT3,PNT4,PNT5,PNT6,PNT7,PNT8,PNT9,PNT10,PNT11,PNT12,PNT13,,
            OUTLIER_REMOVAL/OFF,3
            FILTER/OFF,WAVELENGTH=0
            MOVE/POINT,NORMAL,<25.8,-2,0.3748>
            TIP/T1A105B-180, SHANKIJK=0, -0.9659, -0.2588, ANGLE=0
            MOVE/POINT,NORMAL,<25.8478,-1,3>
            MOVE/POINT,NORMAL,<25.8478,-1,-0.5>
            WORKPLANE/ZPLUS
PLNA VECTOR POINTS=GROUP/SHOWALLPARAMS=YES
PNT14        =FEAT/CONTACT/VECTOR POINT/DEFAULT,POLAR
              THEO/<26.2351,6.1072,0>,<0,0,-1>
              ACTL/<26.2351,6.1072,0>,<0,0,-1>
              TARG/<26.2351,6.1072,0>,<0,0,-1>
              SNAP=NO
              SHOW FEATURE PARAMETERS=NO
              SHOW CONTACT PARAMETERS=YES
                AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              SHOW HITS=NO
PNT15        =FEAT/CONTACT/VECTOR POINT/DEFAULT,POLAR
              THEO/<25.8492,0.5987,0>,<0,0,-1>
              ACTL/<25.8492,0.5987,0>,<0,0,-1>
              TARG/<25.8492,0.5987,0>,<0,0,-1>
              SNAP=NO
              SHOW FEATURE PARAMETERS=NO
              SHOW CONTACT PARAMETERS=YES
                AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              SHOW HITS=NO
              MOVE/POINT,NORMAL,<25.8492,-6.5,-0.5>
              MOVE/POINT,NORMAL,<19,-6.5,-0.5>
PNT16        =FEAT/CONTACT/VECTOR POINT/DEFAULT,POLAR
              THEO/<18.5,0.5312,0>,<0,0,-1>
              ACTL/<18.5,0.5312,0>,<0,0,-1>
              TARG/<18.5,0.5312,0>,<0,0,-1>
              SNAP=NO
              SHOW FEATURE PARAMETERS=NO
              SHOW CONTACT PARAMETERS=YES
                AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              SHOW HITS=NO
PNT17        =FEAT/CONTACT/VECTOR POINT/DEFAULT,POLAR
              THEO/<19.3664,17.9033,0>,<0,0,-1>
              ACTL/<19.3664,17.9033,0>,<0,0,-1>
              TARG/<19.3664,17.9033,0>,<0,0,-1>
              SNAP=NO
              SHOW FEATURE PARAMETERS=NO
              SHOW CONTACT PARAMETERS=YES
                AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              SHOW HITS=NO
              MOVE/POINT,NORMAL,<19,-6.5,-0.5>
              MOVE/POINT,NORMAL,<9.5,-6.5,-0.5>
PNT18        =FEAT/CONTACT/VECTOR POINT/DEFAULT,POLAR
              THEO/<8.9681,1.2077,0>,<0,0,-1>
              ACTL/<8.9681,1.2077,0>,<0,0,-1>
              TARG/<8.9681,1.2077,0>,<0,0,-1>
              SNAP=NO
              SHOW FEATURE PARAMETERS=NO
              SHOW CONTACT PARAMETERS=YES
                AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              SHOW HITS=NO
PNT19        =FEAT/CONTACT/VECTOR POINT/DEFAULT,POLAR
              THEO/<10.8788,33.2165,0>,<0,0,-1>
              ACTL/<10.8788,33.2165,0>,<0,0,-1>
              TARG/<10.8788,33.2165,0>,<0,0,-1>
              SNAP=NO
              SHOW FEATURE PARAMETERS=NO
              SHOW CONTACT PARAMETERS=YES
                AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              SHOW HITS=NO
              MOVE/POINT,NORMAL,<9.5,-6.5,-0.5>
              MOVE/POINT,NORMAL,<3,-6.5,-0.5>
PNT20        =FEAT/CONTACT/VECTOR POINT/DEFAULT,POLAR
              THEO/<2.6084,4.0779,0>,<0,0,-1>
              ACTL/<2.6084,4.0779,0>,<0,0,-1>
              TARG/<2.6084,4.0779,0>,<0,0,-1>
              SNAP=NO
              SHOW FEATURE PARAMETERS=NO
              SHOW CONTACT PARAMETERS=YES
                AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              SHOW HITS=NO
PNT21        =FEAT/CONTACT/VECTOR POINT/DEFAULT,POLAR
              THEO/<6.529,65.9993,0>,<0,0,-1>
              ACTL/<6.529,65.9993,0>,<0,0,-1>
              TARG/<6.529,65.9993,0>,<0,0,-1>
              SNAP=NO
              SHOW FEATURE PARAMETERS=NO
              SHOW CONTACT PARAMETERS=YES
                AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              SHOW HITS=NO
              MOVE/POINT,NORMAL,<3,-1,-0.5>
              TIP/T1A105B-170, SHANKIJK=0.1677, -0.9513, -0.2588, ANGLE=-34.2656
PNT46        =FEAT/CONTACT/VECTOR POINT/DEFAULT,POLAR
              THEO/<7.6754,85.514,0>,<0,0,-1>
              ACTL/<7.6754,85.514,0>,<0,0,-1>
              TARG/<7.6754,85.514,0>,<0,0,-1>
              SNAP=NO
              SHOW FEATURE PARAMETERS=NO
              SHOW CONTACT PARAMETERS=YES
                AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              SHOW HITS=NO
PNT47        =FEAT/CONTACT/VECTOR POINT/DEFAULT,POLAR
              THEO/<0.6682,51.4336,0>,<0,0,-1>
              ACTL/<0.6682,51.4336,0>,<0,0,-1>
              TARG/<0.6682,51.4336,0>,<0,0,-1>
              SNAP=NO
              SHOW FEATURE PARAMETERS=NO
              SHOW CONTACT PARAMETERS=YES
                AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              SHOW HITS=NO
              MOVE/POINT,NORMAL,<1,-6,-0.5>
              TIP/T1A105B90, SHANKIJK=-0.9659, 0, -0.2588, ANGLE=90
              MOVE/POINT,NORMAL,<-3,-6.5,-0.5>
              MOVE/POINT,NORMAL,<-3,11.8,-1>
PNT23        =FEAT/CONTACT/VECTOR POINT/DEFAULT,POLAR
              THEO/<12.2404,73.4433,0>,<0,0,-1>
              ACTL/<12.2404,73.4433,0>,<0,0,-1>
              TARG/<12.2404,73.4433,0>,<0,0,-1>
              SNAP=NO
              SHOW FEATURE PARAMETERS=NO
              SHOW CONTACT PARAMETERS=YES
                AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              SHOW HITS=NO
PNT24        =FEAT/CONTACT/VECTOR POINT/DEFAULT,POLAR
              THEO/<15.0682,70.268,0>,<0,0,-1>
              ACTL/<15.0682,70.268,0>,<0,0,-1>
              TARG/<15.0682,70.268,0>,<0,0,-1>
              SNAP=NO
              SHOW FEATURE PARAMETERS=NO
              SHOW CONTACT PARAMETERS=YES
                AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              SHOW HITS=NO
PNT25        =FEAT/CONTACT/VECTOR POINT/DEFAULT,POLAR
              THEO/<20.4957,80.2999,0>,<0,0,-1>
              ACTL/<20.4957,80.2999,0>,<0,0,-1>
              TARG/<20.4957,80.2999,0>,<0,0,-1>
              SNAP=NO
              SHOW FEATURE PARAMETERS=NO
              SHOW CONTACT PARAMETERS=YES
                AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              SHOW HITS=NO
              MOVE/POINT,NORMAL,<-2.5,20,-1>
              MOVE/POINT,NORMAL,<-2.5,20,8>
              TIP/T1A-105B170, SHANKIJK=0.1677, 0.9513, -0.2588, ANGLE=34.2656
              MOVE/POINT,NORMAL,<1,26.5,8>
              MOVE/POINT,NORMAL,<1,26.5,-0.5>
PNT48        =FEAT/CONTACT/VECTOR POINT/DEFAULT,POLAR
              THEO/<18.7324,88.5898,0>,<0,0,-1>
              ACTL/<18.7324,88.5898,0>,<0,0,-1>
              TARG/<18.7324,88.5898,0>,<0,0,-1>
              SNAP=NO
              SHOW FEATURE PARAMETERS=NO
              SHOW CONTACT PARAMETERS=YES
                AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              SHOW HITS=NO
PNT49        =FEAT/CONTACT/VECTOR POINT/DEFAULT,POLAR
              THEO/<25.8488,88.9401,0>,<0,0,-1>
              ACTL/<25.8488,88.9401,0>,<0,0,-1>
              TARG/<25.8488,88.9401,0>,<0,0,-1>
              SNAP=NO
              SHOW FEATURE PARAMETERS=NO
              SHOW CONTACT PARAMETERS=YES
                AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              SHOW HITS=NO
PNT22        =FEAT/CONTACT/VECTOR POINT/DEFAULT,POLAR
              THEO/<26.0729,84.1607,0>,<0,0,-1>
              ACTL/<26.0729,84.1607,0>,<0,0,-1>
              TARG/<26.0729,84.1607,0>,<0,0,-1>
              SNAP=NO
              SHOW FEATURE PARAMETERS=NO
              SHOW CONTACT PARAMETERS=YES
                AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              SHOW HITS=NO
              MOVE/POINT,NORMAL,<3,29,-0.5>
              TIP/T1A-105B180, SHANKIJK=0, 0.9659, -0.2588, ANGLE=0
              MOVE/POINT,NORMAL,<9.2,29,-0.5>
PNT26        =FEAT/CONTACT/VECTOR POINT/DEFAULT,POLAR
              THEO/<27.6436,69.7299,0>,<0,0,-1>
              ACTL/<27.6436,69.7299,0>,<0,0,-1>
              TARG/<27.6436,69.7299,0>,<0,0,-1>
              SNAP=NO
              SHOW FEATURE PARAMETERS=NO
              SHOW CONTACT PARAMETERS=YES
                AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              SHOW HITS=NO
PNT27        =FEAT/CONTACT/VECTOR POINT/DEFAULT,POLAR
              THEO/<22.4211,64.2187,0>,<0,0,-1>
              ACTL/<22.4211,64.2187,0>,<0,0,-1>
              TARG/<22.4211,64.2187,0>,<0,0,-1>
              SNAP=NO
              SHOW FEATURE PARAMETERS=NO
              SHOW CONTACT PARAMETERS=YES
                AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              SHOW HITS=NO
              MOVE/POINT,NORMAL,<9.2,29,-0.5>
              MOVE/POINT,NORMAL,<18.5,29,-0.5>
PNT28        =FEAT/CONTACT/VECTOR POINT/DEFAULT,POLAR
              THEO/<32.2604,53.5417,0>,<0,0,-1>
              ACTL/<32.2604,53.5417,0>,<0,0,-1>
              TARG/<32.2604,53.5417,0>,<0,0,-1>
              SNAP=NO
              SHOW FEATURE PARAMETERS=NO
              SHOW CONTACT PARAMETERS=YES
                AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              SHOW HITS=NO
PNT29        =FEAT/CONTACT/VECTOR POINT/DEFAULT,POLAR
              THEO/<27.8,46.5471,0>,<0,0,-1>
              ACTL/<27.8,46.5471,0>,<0,0,-1>
              TARG/<27.8,46.5471,0>,<0,0,-1>
              SNAP=NO
              SHOW FEATURE PARAMETERS=NO
              SHOW CONTACT PARAMETERS=YES
                AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              SHOW HITS=NO
              MOVE/POINT,NORMAL,<18.5,29,-0.5>
              MOVE/POINT,NORMAL,<26,29,-0.5>
PNT30        =FEAT/CONTACT/VECTOR POINT/DEFAULT,POLAR
              THEO/<36.2712,44.7865,0>,<0,0,-1>
              ACTL/<36.2712,44.7865,0>,<0,0,-1>
              TARG/<36.2712,44.7865,0>,<0,0,-1>
              SNAP=NO
              SHOW FEATURE PARAMETERS=NO
              SHOW CONTACT PARAMETERS=YES
                AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              SHOW HITS=NO
PNT31        =FEAT/CONTACT/VECTOR POINT/DEFAULT,POLAR
              THEO/<33.3581,39.5128,0>,<0,0,-1>
              ACTL/<33.3581,39.5128,0>,<0,0,-1>
              TARG/<33.3581,39.5128,0>,<0,0,-1>
              SNAP=NO
              SHOW FEATURE PARAMETERS=NO
              SHOW CONTACT PARAMETERS=YES
                AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              SHOW HITS=NO
              MOVE/POINT,NORMAL,<26,29,-0.5>
              MOVE/POINT,NORMAL,<26,29,8>
              TIP/T1A105B-90, SHANKIJK=0.9659, 0, -0.2588, ANGLE=-90
              MOVE/POINT,NORMAL,<30,22,8>
              MOVE/POINT,NORMAL,<30,22,-1>
PNT32        =FEAT/CONTACT/VECTOR POINT/DEFAULT,POLAR
              THEO/<31.6628,39.5427,0>,<0,0,-1>
              ACTL/<31.6628,39.5427,0>,<0,0,-1>
              TARG/<31.6628,39.5427,0>,<0,0,-1>
              SNAP=NO
              SHOW FEATURE PARAMETERS=NO
              SHOW CONTACT PARAMETERS=YES
                AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              SHOW HITS=NO
PNT33        =FEAT/CONTACT/VECTOR POINT/DEFAULT,POLAR
              THEO/<27.7351,27.9311,0>,<0,0,-1>
              ACTL/<27.7351,27.9311,0>,<0,0,-1>
              TARG/<27.7351,27.9311,0>,<0,0,-1>
              SNAP=NO
              SHOW FEATURE PARAMETERS=NO
              SHOW CONTACT PARAMETERS=YES
                AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              SHOW HITS=NO
PNT34        =FEAT/CONTACT/VECTOR POINT/DEFAULT,POLAR
              THEO/<25.2601,13.6339,0>,<0,0,-1>
              ACTL/<25.2601,13.6339,0>,<0,0,-1>
              TARG/<25.2601,13.6339,0>,<0,0,-1>
              SNAP=NO
              SHOW FEATURE PARAMETERS=NO
              SHOW CONTACT PARAMETERS=YES
                AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              SHOW HITS=NO
            ENDGROUP/ID=PLNA VECTOR POINTS
PLNA       =FEAT/PLANE,CARTESIAN,OUTLINE,NO,LEAST_SQR
            THEO/<12.4556,12.9766,0>,<0,0,-1>
            ACTL/<12.4556,12.9766,0>,<0,0,-1>
            CONSTR/PLANE,BF,PNT14,PNT15,PNT16,PNT17,PNT18,PNT19,PNT20,PNT21,PNT23,PNT24,PNT25,PNT22,PNT26,PNT27,PNT28,PNT29,PNT30,PNT31,PNT32,PNT33,PNT34,PNT49,PNT48,PNT46,PNT47,,
            OUTLIER_REMOVAL/OFF,3
            FILTER/OFF,WAVELENGTH=0
            MOVE/POINT,NORMAL,<30,7,-1>
            MOVE/POINT,NORMAL,<30,7,8>
            TIP/T1A10B90, SHANKIJK=-0.1736, 0, 0.9848, ANGLE=90
            MOVE/POINT,NORMAL,<30,7,8>
            MOVE/POINT,NORMAL,<0,7,8>
PLNB VECTOR POINTS=GROUP/SHOWALLPARAMS=YES
PNT35        =FEAT/CONTACT/VECTOR POINT/DEFAULT,POLAR
              THEO/<0.1243,90,0.6971>,<-1,0,0>
              ACTL/<0.1243,90,0.6971>,<-1,0,0>
              TARG/<0.1243,90,0.6971>,<-1,0,0>
              SNAP=NO
              SHOW FEATURE PARAMETERS=NO
              SHOW CONTACT PARAMETERS=YES
                AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              SHOW HITS=NO
PNT36        =FEAT/CONTACT/VECTOR POINT/DEFAULT,POLAR
              THEO/<0.1404,90,0.0641>,<-1,0,0>
              ACTL/<0.1404,90,0.0641>,<-1,0,0>
              TARG/<0.1404,90,0.0641>,<-1,0,0>
              SNAP=NO
              SHOW FEATURE PARAMETERS=NO
              SHOW CONTACT PARAMETERS=YES
                AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              SHOW HITS=NO
              MOVE/POINT,NORMAL,<-0.2295,0.1404,0.7>
              MOVE/POINT,NORMAL,<-0.2295,2.5,0.7>
PNT37        =FEAT/CONTACT/VECTOR POINT/DEFAULT,POLAR
              THEO/<3.8476,90,0.0427>,<-1,0,0>
              ACTL/<3.8476,90,0.0427>,<-1,0,0>
              TARG/<3.8476,90,0.0427>,<-1,0,0>
              SNAP=NO
              SHOW FEATURE PARAMETERS=NO
              SHOW CONTACT PARAMETERS=YES
                AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              SHOW HITS=NO
PNT38        =FEAT/CONTACT/VECTOR POINT/DEFAULT,POLAR
              THEO/<7.018,90,0.0324>,<-1,0,0>
              ACTL/<7.018,90,0.0324>,<-1,0,0>
              TARG/<7.018,90,0.0324>,<-1,0,0>
              SNAP=NO
              SHOW FEATURE PARAMETERS=NO
              SHOW CONTACT PARAMETERS=YES
                AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              SHOW HITS=NO
PNT39        =FEAT/CONTACT/VECTOR POINT/DEFAULT,POLAR
              THEO/<10.6898,90,0.0332>,<-1,0,0>
              ACTL/<10.6898,90,0.0332>,<-1,0,0>
              TARG/<10.6898,90,0.0332>,<-1,0,0>
              SNAP=NO
              SHOW FEATURE PARAMETERS=NO
              SHOW CONTACT PARAMETERS=YES
                AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              SHOW HITS=NO
              MOVE/POINT,NORMAL,<-0.2295,10.6898,0.7>
              MOVE/POINT,NORMAL,<-0.2295,14,0.7>
PNT40        =FEAT/CONTACT/VECTOR POINT/DEFAULT,POLAR
              THEO/<14.3484,90,0.0478>,<-1,0,0>
              ACTL/<14.3484,90,0.0478>,<-1,0,0>
              TARG/<14.3484,90,0.0478>,<-1,0,0>
              SNAP=NO
              SHOW FEATURE PARAMETERS=NO
              SHOW CONTACT PARAMETERS=YES
                AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              SHOW HITS=NO
PNT41        =FEAT/CONTACT/VECTOR POINT/DEFAULT,POLAR
              THEO/<17.8816,90,0.0405>,<-1,0,0>
              ACTL/<17.8816,90,0.0405>,<-1,0,0>
              TARG/<17.8816,90,0.0405>,<-1,0,0>
              SNAP=NO
              SHOW FEATURE PARAMETERS=NO
              SHOW CONTACT PARAMETERS=YES
                AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              SHOW HITS=NO
PNT42        =FEAT/CONTACT/VECTOR POINT/DEFAULT,POLAR
              THEO/<21.1727,90,0.0405>,<-1,0,0>
              ACTL/<21.1727,90,0.0405>,<-1,0,0>
              TARG/<21.1727,90,0.0405>,<-1,0,0>
              SNAP=NO
              SHOW FEATURE PARAMETERS=NO
              SHOW CONTACT PARAMETERS=YES
                AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              SHOW HITS=NO
              MOVE/POINT,NORMAL,<-0.2295,21.1727,0.3>
              MOVE/POINT,NORMAL,<-0.2295,24.25,0.3>
PNT43        =FEAT/CONTACT/VECTOR POINT/DEFAULT,POLAR
              THEO/<24.2576,90,0.047>,<-1,0,0>
              ACTL/<24.2576,90,0.047>,<-1,0,0>
              TARG/<24.2576,90,0.047>,<-1,0,0>
              SNAP=NO
              SHOW FEATURE PARAMETERS=NO
              SHOW CONTACT PARAMETERS=YES
                AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              SHOW HITS=NO
              MOVE/POINT,NORMAL,<-0.2295,24.25,0.7>
              MOVE/POINT,NORMAL,<-0.2295,26,0.8>
PNT44        =FEAT/CONTACT/VECTOR POINT/DEFAULT,POLAR
              THEO/<26.0264,90,0.729>,<-1,0,0>
              ACTL/<26.0264,90,0.729>,<-1,0,0>
              TARG/<26.0264,90,0.729>,<-1,0,0>
              SNAP=NO
              SHOW FEATURE PARAMETERS=NO
              SHOW CONTACT PARAMETERS=YES
                AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              SHOW HITS=NO
PNT45        =FEAT/CONTACT/VECTOR POINT/DEFAULT,POLAR
              THEO/<26,90,0.1275>,<-1,0,0>
              ACTL/<26,90,0.1275>,<-1,0,0>
              TARG/<26,90,0.1275>,<-1,0,0>
              SNAP=NO
              SHOW FEATURE PARAMETERS=NO
              SHOW CONTACT PARAMETERS=YES
                AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              SHOW HITS=NO
            ENDGROUP/ID=PLNB VECTOR POINTS
PLNB       =FEAT/PLANE,CARTESIAN,OUTLINE,NO,LEAST_SQR
            THEO/<0,13.7733,0.1729>,<-1,0,0>
            ACTL/<0,13.7733,0.1729>,<-1,0,0>
            CONSTR/PLANE,BF,PNT35,PNT36,PNT37,PNT38,PNT39,PNT40,PNT41,PNT42,PNT43,PNT44,PNT45,,
            OUTLIER_REMOVAL/OFF,3
            FILTER/OFF,WAVELENGTH=0
A2         =ALIGNMENT/START,RECALL:STARTUP,LIST=YES
              ALIGNMENT/LEVEL,ZMINUS,PLNA
              ALIGNMENT/TRANS,ZAXIS,PLNA
              ALIGNMENT/ROTATE,XMINUS,TO,PLNB,ABOUT,ZMINUS
              ALIGNMENT/TRANS,XAXIS,PLNB
              ALIGNMENT/TRANS,YAXIS,PLNC
            ALIGNMENT/END
            MOVE/POINT,NORMAL,<-0.2295,25.7,6>
            TIP/T1A-10B0, SHANKIJK=0, -0.1736, 0.9848, ANGLE=0
PLN1       =FEAT/CONTACT/PLANE/DEFAULT,CARTESIAN,OUTLINE,LEAST_SQR
            THEO/<0.6897,25.9023,0.7596>,<0,-1,0>
            ACTL/<0.6897,25.9023,0.7596>,<0,-1,0>
            TARG/<0.6897,25.9023,0.7596>,<0,-1,0>
            ANGLE VEC=<1,0,0>,SQUARE
            SHOW FEATURE PARAMETERS=NO
            SHOW CONTACT PARAMETERS=YES
              NUMHITS=2,NUMROWS=2
              SPACER=0
              AVOIDANCE MOVE=NO
              USE BOUNDARY OFFSET=YES,OFFSET=0.0394
            SHOW HITS=NO
            MOVE/POINT,NORMAL,<0.1564,25.6728,2>
            TIP/T1A10B90, SHANKIJK=-0.1736, 0, 0.9848, ANGLE=90
            MOVE/POINT,NORMAL,<0.1564,22,2>
PLN2       =FEAT/CONTACT/PLANE/DEFAULT,CARTESIAN,OUTLINE,LEAST_SQR
            THEO/<1.1787,20.4557,0.7326>,<-1,0,0>
            ACTL/<1.1787,20.4557,0.7326>,<-1,0,0>
            TARG/<1.1787,20.4557,0.7326>,<-1,0,0>
            ANGLE VEC=<0,0,-1>,SQUARE
            SHOW FEATURE PARAMETERS=NO
            SHOW CONTACT PARAMETERS=YES
              NUMHITS=10,NUMROWS=2
              SPACER=0
              AVOIDANCE MOVE=NO
            SHOW HITS=NO
            MOVE/POINT,NORMAL,<0.9492,0.4475,2.5>
            TIP/T1A10B0, SHANKIJK=0, 0.1736, 0.9848, ANGLE=0
            MOVE/POINT,NORMAL,<0.9492,0.4475,1.5>
PLN3       =FEAT/CONTACT/PLANE/DEFAULT,CARTESIAN,OUTLINE,LEAST_SQR
            THEO/<0.8811,0.2392,0.6575>,<0,1,0>
            ACTL/<0.8811,0.2392,0.6575>,<0,1,0>
            TARG/<0.8811,0.2392,0.6575>,<0,1,0>
            ANGLE VEC=<-1,0,0>,SQUARE
            SHOW FEATURE PARAMETERS=NO
            SHOW CONTACT PARAMETERS=YES
              NUMHITS=2,NUMROWS=2
              SPACER=0
              AVOIDANCE MOVE=NO
              USE BOUNDARY OFFSET=YES,OFFSET=0.0394
            SHOW HITS=NO
            TIP/T1A0B0, SHANKIJK=0, 0, 1, ANGLE=0
PLN4       =FEAT/CONTACT/PLANE/DEFAULT,CARTESIAN,OUTLINE,LEAST_SQR
            THEO/<0.8629,20.8596,0.08>,<0,0,1>
            ACTL/<0.8629,20.8596,0.08>,<0,0,1>
            TARG/<0.8629,20.8596,0.08>,<0,0,1>
            ANGLE VEC=<1,0,0>,SQUARE
            SHOW FEATURE PARAMETERS=NO
            SHOW CONTACT PARAMETERS=YES
              NUMHITS=5,NUMROWS=2
              SPACER=0
              AVOIDANCE MOVE=NO
              USE BOUNDARY OFFSET=YES,OFFSET=0.0394
            SHOW HITS=NO
            CLEARP/ZPLUS,2,ZPLUS,2,ON
            MOVE/CLEARPLANE
            TIP/T1A10B0, SHANKIJK=0, 0.1736, 0.9848, ANGLE=0
            CLEARP/ZPLUS,2,ZPLUS,2,OFF
PLN5       =FEAT/PLANE,CARTESIAN,OUTLINE
            THEO/<13.9839,0.06,0.8422>,<0,1,0>
            ACTL/<13.9839,0.06,0.8422>,<0,1,0>
            MEAS/PLANE,13
              HIT/BASIC,NORMAL,<1.5561,0.06,1.0734>,<0,1,0>,<1.5561,0.06,1.0734>,USE THEO=YES
              HIT/BASIC,NORMAL,<1.5567,0.06,0.7791>,<0,1,0>,<1.5567,0.06,0.7791>,USE THEO=YES
              HIT/BASIC,NORMAL,<4.1699,0.06,1.0714>,<0,1,0>,<4.1699,0.06,1.0714>,USE THEO=YES
              HIT/BASIC,NORMAL,<6.5737,0.06,0.7859>,<0,1,0>,<6.5737,0.06,0.7859>,USE THEO=YES
              HIT/BASIC,NORMAL,<9.4337,0.06,1.0559>,<0,1,0>,<9.4337,0.06,1.0559>,USE THEO=YES
              HIT/BASIC,NORMAL,<12.7182,0.06,0.773>,<0,1,0>,<12.7182,0.06,0.773>,USE THEO=YES
              MOVE/POINT,NORMAL,<13.5355,0.2881,1.6>
              MOVE/POINT,NORMAL,<14.113,0.2905,1.6>
              HIT/BASIC,NORMAL,<14.6912,0.06,1.0806>,<0,1,0>,<14.6912,0.06,1.0806>,USE THEO=YES
              HIT/BASIC,NORMAL,<16.7152,0.06,0.7917>,<0,1,0>,<16.7152,0.06,0.7917>,USE THEO=YES
              HIT/BASIC,NORMAL,<19.2592,0.06,1.0571>,<0,1,0>,<19.2592,0.06,1.0571>,USE THEO=YES
              HIT/BASIC,NORMAL,<21.5622,0.06,0.7867>,<0,1,0>,<21.5622,0.06,0.7867>,USE THEO=YES
              HIT/BASIC,NORMAL,<23.2716,0.06,0.9999>,<0,1,0>,<23.2716,0.06,0.9999>,USE THEO=YES
              HIT/BASIC,NORMAL,<25.8983,0.06,0.4209>,<0,1,0>,<25.8983,0.06,0.4209>,USE THEO=YES
              HIT/BASIC,NORMAL,<24.3851,0.06,0.2735>,<0,1,0>,<24.3851,0.06,0.2735>,USE THEO=YES
            ENDMEAS/
PLN6       =FEAT/PLANE,CARTESIAN,OUTLINE
            THEO/<12.9814,0.2555,0.3049>,<0,1,0>
            ACTL/<12.9814,0.2555,0.3049>,<0,1,0>
            MEAS/PLANE,10
              HIT/BASIC,NORMAL,<24.207,0.2555,0.0577>,<0,1,0>,<24.207,0.2555,0.0577>,USE THEO=YES
              HIT/BASIC,NORMAL,<24.0441,0.2555,0.5387>,<0,1,0>,<24.0441,0.2555,0.5387>,USE THEO=YES
              HIT/BASIC,NORMAL,<20.6758,0.2555,0.0336>,<0,1,0>,<20.6758,0.2555,0.0336>,USE THEO=YES
              HIT/BASIC,NORMAL,<17.6988,0.2555,0.5628>,<0,1,0>,<17.6988,0.2555,0.5628>,USE THEO=YES
              HIT/BASIC,NORMAL,<14.5183,0.2555,0.0537>,<0,1,0>,<14.5183,0.2555,0.0537>,USE THEO=YES
              MOVE/POINT,NORMAL,<14.2641,2.5,0.0943>
              MOVE/POINT,NORMAL,<13.4276,2.5,0.2278>
              HIT/BASIC,NORMAL,<11.1915,0.2555,0.578>,<0,1,0>,<11.1915,0.2555,0.578>,USE THEO=YES
              HIT/BASIC,NORMAL,<8.5331,0.2555,0.0652>,<0,1,0>,<8.5331,0.2555,0.0652>,USE THEO=YES
              HIT/BASIC,NORMAL,<5.7747,0.2555,0.5504>,<0,1,0>,<5.7747,0.2555,0.5504>,USE THEO=YES
              HIT/BASIC,NORMAL,<1.5816,0.2555,0.0471>,<0,1,0>,<1.5816,0.2555,0.0471>,USE THEO=YES
              HIT/BASIC,NORMAL,<1.5886,0.2555,0.5622>,<0,1,0>,<1.5886,0.2555,0.5622>,USE THEO=YES
            ENDMEAS/
            CLEARP/ZPLUS,2,ZPLUS,2,ON
            MOVE/CLEARPLANE
            TIP/T1A-10B90, SHANKIJK=0.1736, 0, 0.9848, ANGLE=90
PLN7       =FEAT/PLANE,CARTESIAN,OUTLINE
            THEO/<1.2587,2.996,0.7179>,<1,0,0>
            ACTL/<1.2587,2.996,0.7179>,<1,0,0>
            MEAS/PLANE,5
              MOVE/CLEARPLANE
              HIT/BASIC,NORMAL,<1.2587,0.412,0.9745>,<1,0,0>,<1.2587,0.412,0.9745>,USE THEO=YES
              HIT/BASIC,NORMAL,<1.2587,0.5985,0.0411>,<1,0,0>,<1.2587,0.5985,0.0411>,USE THEO=YES
              HIT/BASIC,NORMAL,<1.2587,2.9004,1.0094>,<1,0,0>,<1.2587,2.9004,1.0094>,USE THEO=YES
              HIT/BASIC,NORMAL,<1.2587,5.5169,0.0382>,<1,0,0>,<1.2587,5.5169,0.0382>,USE THEO=YES
              HIT/BASIC,NORMAL,<1.2587,5.5521,1.5262>,<1,0,0>,<1.2587,5.5521,1.5262>,USE THEO=YES
            ENDMEAS/
            MOVE/CLEARPLANE
            TIP/T1A-10B0, SHANKIJK=0, -0.1736, 0.9848, ANGLE=0
PLN8       =FEAT/PLANE,CARTESIAN,OUTLINE
            THEO/<13.1703,5.8785,0.8847>,<0,-1,0>
            ACTL/<13.1703,5.8785,0.8847>,<0,-1,0>
            MEAS/PLANE,9
              MOVE/CLEARPLANE
              HIT/BASIC,NORMAL,<1.5923,5.8785,1.5918>,<0,-1,0>,<1.5923,5.8785,1.5918>,USE THEO=YES
              HIT/BASIC,NORMAL,<1.5894,5.8785,0.0599>,<0,-1,0>,<1.5894,5.8785,0.0599>,USE THEO=YES
              HIT/BASIC,NORMAL,<5.9449,5.8785,1.5151>,<0,-1,0>,<5.9449,5.8785,1.5151>,USE THEO=YES
              HIT/BASIC,NORMAL,<9.6761,5.8785,0.0892>,<0,-1,0>,<9.6761,5.8785,0.0892>,USE THEO=YES
              HIT/BASIC,NORMAL,<13.4655,5.8785,1.553>,<0,-1,0>,<13.4655,5.8785,1.553>,USE THEO=YES
              HIT/BASIC,NORMAL,<17.4277,5.8785,0.1281>,<0,-1,0>,<17.4277,5.8785,0.1281>,USE THEO=YES
              HIT/BASIC,NORMAL,<20.6084,5.8785,1.4731>,<0,-1,0>,<20.6084,5.8785,1.4731>,USE THEO=YES
              HIT/BASIC,NORMAL,<24.1339,5.8785,0.0805>,<0,-1,0>,<24.1339,5.8785,0.0805>,USE THEO=YES
              HIT/BASIC,NORMAL,<24.095,5.8785,1.4715>,<0,-1,0>,<24.095,5.8785,1.4715>,USE THEO=YES
            ENDMEAS/
            MOVE/CLEARPLANE
            TIP/T1A10B90, SHANKIJK=-0.1736, 0, 0.9848, ANGLE=90
PLN9       =FEAT/PLANE,CARTESIAN,OUTLINE
            THEO/<24.5011,3.1412,0.549>,<-1,0,0>
            ACTL/<24.5011,3.1412,0.549>,<-1,0,0>
            MEAS/PLANE,6
              MOVE/CLEARPLANE
              HIT/BASIC,NORMAL,<24.5011,0.5777,0.0447>,<-1,0,0>,<24.5011,0.5777,0.0447>,USE THEO=YES
              HIT/BASIC,NORMAL,<24.5011,1.8038,0.0874>,<-1,0,0>,<24.5011,1.8038,0.0874>,USE THEO=YES
              HIT/BASIC,NORMAL,<24.5011,1.8989,0.7944>,<-1,0,0>,<24.5011,1.8989,0.7944>,USE THEO=YES
              HIT/BASIC,NORMAL,<24.5011,3.5333,0.8453>,<-1,0,0>,<24.5011,3.5333,0.8453>,USE THEO=YES
              HIT/BASIC,NORMAL,<24.5011,5.5162,0.0926>,<-1,0,0>,<24.5011,5.5162,0.0926>,USE THEO=YES
              HIT/BASIC,NORMAL,<24.5011,5.5174,1.4293>,<-1,0,0>,<24.5011,5.5174,1.4293>,USE THEO=YES
            ENDMEAS/
            MOVE/CLEARPLANE
PLN10      =FEAT/PLANE,CARTESIAN,OUTLINE
            THEO/<24.5011,8.8477,0.6591>,<-1,0,0>
            ACTL/<24.5011,8.8477,0.6591>,<-1,0,0>
            MEAS/PLANE,5
              MOVE/CLEARPLANE
              HIT/BASIC,NORMAL,<24.5011,6.3807,1.4511>,<-1,0,0>,<24.5011,6.3807,1.4511>,USE THEO=YES
              HIT/BASIC,NORMAL,<24.5011,6.3797,0.064>,<-1,0,0>,<24.5011,6.3797,0.064>,USE THEO=YES
              HIT/BASIC,NORMAL,<24.5011,8.8234,0.8746>,<-1,0,0>,<24.5011,8.8234,0.8746>,USE THEO=YES
              HIT/BASIC,NORMAL,<24.5011,11.3283,0.0624>,<-1,0,0>,<24.5011,11.3283,0.0624>,USE THEO=YES
              HIT/BASIC,NORMAL,<24.5011,11.3265,0.8435>,<-1,0,0>,<24.5011,11.3265,0.8435>,USE THEO=YES
            ENDMEAS/
            MOVE/CLEARPLANE
            TIP/T1A-10B0, SHANKIJK=0, -0.1736, 0.9848, ANGLE=0
PLN11      =FEAT/PLANE,CARTESIAN,OUTLINE
            THEO/<13.2911,11.6575,0.537>,<0,-1,0>
            ACTL/<13.2911,11.6575,0.537>,<0,-1,0>
            MEAS/PLANE,10
              MOVE/CLEARPLANE
              HIT/BASIC,NORMAL,<24.106,11.6575,0.8477>,<0,-1,0>,<24.106,11.6575,0.8477>,USE THEO=YES
              HIT/BASIC,NORMAL,<24.146,11.6575,0.07>,<0,-1,0>,<24.146,11.6575,0.07>,USE THEO=YES
              HIT/BASIC,NORMAL,<21.0701,11.6575,0.8943>,<0,-1,0>,<21.0701,11.6575,0.8943>,USE THEO=YES
              HIT/BASIC,NORMAL,<17.4338,11.6575,0.0463>,<0,-1,0>,<17.4338,11.6575,0.0463>,USE THEO=YES
              HIT/BASIC,NORMAL,<14.6558,11.6575,0.8286>,<0,-1,0>,<14.6558,11.6575,0.8286>,USE THEO=YES
              MOVE/POINT,NORMAL,<14.1764,11.4274,1.6>
              MOVE/POINT,NORMAL,<13.4367,11.4289,1.6>
              HIT/BASIC,NORMAL,<12.5433,11.6575,0.7964>,<0,-1,0>,<12.5433,11.6575,0.7964>,USE THEO=YES
              HIT/BASIC,NORMAL,<9.7732,11.6575,0.0558>,<0,-1,0>,<9.7732,11.6575,0.0558>,USE THEO=YES
              HIT/BASIC,NORMAL,<6.0335,11.6575,0.8929>,<0,-1,0>,<6.0335,11.6575,0.8929>,USE THEO=YES
              HIT/BASIC,NORMAL,<1.5897,11.6575,0.0359>,<0,-1,0>,<1.5897,11.6575,0.0359>,USE THEO=YES
              HIT/BASIC,NORMAL,<1.5599,11.6575,0.9023>,<0,-1,0>,<1.5599,11.6575,0.9023>,USE THEO=YES
            ENDMEAS/
            MOVE/CLEARPLANE
            TIP/T1A-10B90, SHANKIJK=0.1736, 0, 0.9848, ANGLE=90
PLN12      =FEAT/PLANE,CARTESIAN,OUTLINE
            THEO/<1.2587,13.0418,1.0384>,<1,0,0>
            ACTL/<1.2587,13.0418,1.0384>,<1,0,0>
            MEAS/PLANE,16
              MOVE/CLEARPLANE
              HIT/BASIC,NORMAL,<1.2587,6.3779,0.0892>,<1,0,0>,<1.2587,6.3779,0.0892>,USE THEO=YES
              MOVE/POINT,NORMAL,<1.4881,6.4443,1.6673>
              HIT/BASIC,NORMAL,<1.2587,5.8918,1.8568>,<1,0,0>,<1.2587,5.8918,1.8568>,USE THEO=YES
              HIT/BASIC,NORMAL,<1.2587,8.837,1.8622>,<1,0,0>,<1.2587,8.837,1.8622>,USE THEO=YES
              HIT/BASIC,NORMAL,<1.2587,11.2453,0.0508>,<1,0,0>,<1.2587,11.2453,0.0508>,USE THEO=YES
              HIT/BASIC,NORMAL,<1.2587,10.5824,1.8171>,<1,0,0>,<1.2587,10.5824,1.8171>,USE THEO=YES
              HIT/BASIC,NORMAL,<1.2587,11.3129,1.1795>,<1,0,0>,<1.2587,11.3129,1.1795>,USE THEO=YES
              HIT/BASIC,NORMAL,<1.2587,12.0809,1.1454>,<1,0,0>,<1.2587,12.0809,1.1454>,USE THEO=YES
              HIT/BASIC,NORMAL,<1.2587,12.0427,0.2453>,<1,0,0>,<1.2587,12.0427,0.2453>,USE THEO=YES
              HIT/BASIC,NORMAL,<1.2587,14.1034,0.2349>,<1,0,0>,<1.2587,14.1034,0.2349>,USE THEO=YES
              HIT/BASIC,NORMAL,<1.2587,14.1038,1.1884>,<1,0,0>,<1.2587,14.1038,1.1884>,USE THEO=YES
              HIT/BASIC,NORMAL,<1.2587,14.8466,1.191>,<1,0,0>,<1.2587,14.8466,1.191>,USE THEO=YES
              HIT/BASIC,NORMAL,<1.2587,15.2951,1.8597>,<1,0,0>,<1.2587,15.2951,1.8597>,USE THEO=YES
              HIT/BASIC,NORMAL,<1.2587,14.8505,0.0881>,<1,0,0>,<1.2587,14.8505,0.0881>,USE THEO=YES
              HIT/BASIC,NORMAL,<1.2587,19.7325,0.0845>,<1,0,0>,<1.2587,19.7325,0.0845>,USE THEO=YES
              HIT/BASIC,NORMAL,<1.2587,17.2024,1.8304>,<1,0,0>,<1.2587,17.2024,1.8304>,USE THEO=YES
              HIT/BASIC,NORMAL,<1.2587,20.1639,1.8904>,<1,0,0>,<1.2587,20.1639,1.8904>,USE THEO=YES
            ENDMEAS/
            MOVE/CLEARPLANE
            TIP/T1A10B0, SHANKIJK=0, 0.1736, 0.9848, ANGLE=0
PLN13      =FEAT/PLANE,CARTESIAN,OUTLINE
            THEO/<12.8531,6.0345,0.9055>,<0,1,0>
            ACTL/<12.8531,6.0345,0.9055>,<0,1,0>
            MEAS/PLANE,9
              MOVE/CLEARPLANE
              HIT/BASIC,NORMAL,<1.6116,6.0345,1.6173>,<0,1,0>,<1.6116,6.0345,1.6173>,USE THEO=YES
              HIT/BASIC,NORMAL,<1.5683,6.0345,0.0354>,<0,1,0>,<1.5683,6.0345,0.0354>,USE THEO=YES
              HIT/BASIC,NORMAL,<5.706,6.0345,1.5884>,<0,1,0>,<5.706,6.0345,1.5884>,USE THEO=YES
              HIT/BASIC,NORMAL,<9.2203,6.0345,0.0612>,<0,1,0>,<9.2203,6.0345,0.0612>,USE THEO=YES
              HIT/BASIC,NORMAL,<13.1503,6.0345,1.5288>,<0,1,0>,<13.1503,6.0345,1.5288>,USE THEO=YES
              HIT/BASIC,NORMAL,<15.9789,6.0345,0.0762>,<0,1,0>,<15.9789,6.0345,0.0762>,USE THEO=YES
              HIT/BASIC,NORMAL,<20.0932,6.0345,1.6039>,<0,1,0>,<20.0932,6.0345,1.6039>,USE THEO=YES
              HIT/BASIC,NORMAL,<24.1882,6.0345,0.0531>,<0,1,0>,<24.1882,6.0345,0.0531>,USE THEO=YES
              HIT/BASIC,NORMAL,<24.1611,6.0345,1.5855>,<0,1,0>,<24.1611,6.0345,1.5855>,USE THEO=YES
            ENDMEAS/
            MOVE/CLEARPLANE
            TIP/T1A-10B0, SHANKIJK=0, -0.1736, 0.9848, ANGLE=0
PLN14      =FEAT/PLANE,CARTESIAN,OUTLINE
            THEO/<18.769,11.7075,1.4741>,<0,-1,0>
            ACTL/<18.769,11.7075,1.4741>,<0,-1,0>
            MEAS/PLANE,4
              MOVE/CLEARPLANE
              HIT/BASIC,NORMAL,<19.4595,11.7075,1.8501>,<0,-1,0>,<19.4595,11.7075,1.8501>,USE THEO=YES
              HIT/BASIC,NORMAL,<19.7268,11.7075,1.0961>,<0,-1,0>,<19.7268,11.7075,1.0961>,USE THEO=YES
              HIT/BASIC,NORMAL,<17.7847,11.7075,1.0994>,<0,-1,0>,<17.7847,11.7075,1.0994>,USE THEO=YES
              HIT/BASIC,NORMAL,<18.1049,11.7075,1.8506>,<0,-1,0>,<18.1049,11.7075,1.8506>,USE THEO=YES
            ENDMEAS/
PLN15      =FEAT/PLANE,CARTESIAN,OUTLINE
            THEO/<9.599,14.4239,0.5968>,<0,-1,0>
            ACTL/<9.599,14.4239,0.5968>,<0,-1,0>
            MEAS/PLANE,9
              MOVE/CLEARPLANE
              HIT/BASIC,NORMAL,<1.6014,14.4239,0.8681>,<0,-1,0>,<1.6014,14.4239,0.8681>,USE THEO=YES
              HIT/BASIC,NORMAL,<1.556,14.4239,0.224>,<0,-1,0>,<1.556,14.4239,0.224>,USE THEO=YES
              HIT/BASIC,NORMAL,<4.7056,14.4239,0.9101>,<0,-1,0>,<4.7056,14.4239,0.9101>,USE THEO=YES
              HIT/BASIC,NORMAL,<7.0125,14.4239,0.2068>,<0,-1,0>,<7.0125,14.4239,0.2068>,USE THEO=YES
              HIT/BASIC,NORMAL,<9.9855,14.4239,0.9032>,<0,-1,0>,<9.9855,14.4239,0.9032>,USE THEO=YES
              HIT/BASIC,NORMAL,<12.4802,14.4239,0.2332>,<0,-1,0>,<12.4802,14.4239,0.2332>,USE THEO=YES
              HIT/BASIC,NORMAL,<14.7063,14.4239,0.9066>,<0,-1,0>,<14.7063,14.4239,0.9066>,USE THEO=YES
              HIT/BASIC,NORMAL,<17.1815,14.4239,0.2064>,<0,-1,0>,<17.1815,14.4239,0.2064>,USE THEO=YES
              HIT/BASIC,NORMAL,<17.162,14.4239,0.9127>,<0,-1,0>,<17.162,14.4239,0.9127>,USE THEO=YES
            ENDMEAS/
PLN16      =FEAT/PLANE,CARTESIAN,OUTLINE
            THEO/<18.7481,14.3089,0.9878>,<0,-1,0>
            ACTL/<18.7481,14.3089,0.9878>,<0,-1,0>
            MEAS/PLANE,6
              MOVE/CLEARPLANE
              HIT/BASIC,NORMAL,<17.5686,14.3089,0.2306>,<0,-1,0>,<17.5686,14.3089,0.2306>,USE THEO=YES
              HIT/BASIC,NORMAL,<17.5715,14.3089,0.8884>,<0,-1,0>,<17.5715,14.3089,0.8884>,USE THEO=YES
              HIT/BASIC,NORMAL,<18.065,14.3089,1.8258>,<0,-1,0>,<18.065,14.3089,1.8258>,USE THEO=YES
              HIT/BASIC,NORMAL,<19.4557,14.3089,1.8378>,<0,-1,0>,<19.4557,14.3089,1.8378>,USE THEO=YES
              HIT/BASIC,NORMAL,<19.9185,14.3089,0.9087>,<0,-1,0>,<19.9185,14.3089,0.9087>,USE THEO=YES
              HIT/BASIC,NORMAL,<19.9091,14.3089,0.2354>,<0,-1,0>,<19.9091,14.3089,0.2354>,USE THEO=YES
            ENDMEAS/
PLN17      =FEAT/PLANE,CARTESIAN,OUTLINE
            THEO/<22.2386,14.4239,0.4942>,<0,-1,0>
            ACTL/<22.2386,14.4239,0.4942>,<0,-1,0>
            MEAS/PLANE,5
              MOVE/CLEARPLANE
              HIT/BASIC,NORMAL,<20.359,14.4239,0.2348>,<0,-1,0>,<20.359,14.4239,0.2348>,USE THEO=YES
              HIT/BASIC,NORMAL,<20.3547,14.4239,0.8777>,<0,-1,0>,<20.3547,14.4239,0.8777>,USE THEO=YES
              HIT/BASIC,NORMAL,<22.0933,14.4239,0.2485>,<0,-1,0>,<22.0933,14.4239,0.2485>,USE THEO=YES
              HIT/BASIC,NORMAL,<24.1859,14.4239,0.9025>,<0,-1,0>,<24.1859,14.4239,0.9025>,USE THEO=YES
              HIT/BASIC,NORMAL,<24.2003,14.4239,0.2076>,<0,-1,0>,<24.2003,14.4239,0.2076>,USE THEO=YES
            ENDMEAS/
            MOVE/CLEARPLANE
            TIP/T1A10B90, SHANKIJK=-0.1736, 0, 0.9848, ANGLE=90
PLN18      =FEAT/PLANE,CARTESIAN,OUTLINE
            THEO/<24.5011,13.0878,0.5644>,<-1,0,0>
            ACTL/<24.5011,13.0878,0.5644>,<-1,0,0>
            MEAS/PLANE,4
              MOVE/CLEARPLANE
              HIT/BASIC,NORMAL,<24.5011,14.1269,0.8881>,<-1,0,0>,<24.5011,14.1269,0.8881>,USE THEO=YES
              HIT/BASIC,NORMAL,<24.5011,14.1342,0.236>,<-1,0,0>,<24.5011,14.1342,0.236>,USE THEO=YES
              HIT/BASIC,NORMAL,<24.5011,12.038,0.8964>,<-1,0,0>,<24.5011,12.038,0.8964>,USE THEO=YES
              HIT/BASIC,NORMAL,<24.5011,12.052,0.2372>,<-1,0,0>,<24.5011,12.052,0.2372>,USE THEO=YES
            ENDMEAS/
            MOVE/CLEARPLANE
            TIP/T1A10B0, SHANKIJK=0, 0.1736, 0.9848, ANGLE=0
PLN19      =FEAT/PLANE,CARTESIAN,OUTLINE
            THEO/<22.3099,11.7175,0.4912>,<0,1,0>
            ACTL/<22.3099,11.7175,0.4912>,<0,1,0>
            MEAS/PLANE,5
              MOVE/CLEARPLANE
              HIT/BASIC,NORMAL,<24.2036,11.7175,0.2197>,<0,1,0>,<24.2036,11.7175,0.2197>,USE THEO=YES
              HIT/BASIC,NORMAL,<24.1536,11.7175,0.9028>,<0,1,0>,<24.1536,11.7175,0.9028>,USE THEO=YES
              HIT/BASIC,NORMAL,<22.4493,11.7175,0.2166>,<0,1,0>,<22.4493,11.7175,0.2166>,USE THEO=YES
              HIT/BASIC,NORMAL,<20.3616,11.7175,0.9033>,<0,1,0>,<20.3616,11.7175,0.9033>,USE THEO=YES
              HIT/BASIC,NORMAL,<20.3813,11.7175,0.2133>,<0,1,0>,<20.3813,11.7175,0.2133>,USE THEO=YES
            ENDMEAS/
PLN20      =FEAT/PLANE,CARTESIAN,OUTLINE
            THEO/<18.7712,11.8325,0.9896>,<0,1,0>
            ACTL/<18.7712,11.8325,0.9896>,<0,1,0>
            MEAS/PLANE,6
              MOVE/CLEARPLANE
              HIT/BASIC,NORMAL,<19.9622,11.8325,0.2073>,<0,1,0>,<19.9622,11.8325,0.2073>,USE THEO=YES
              HIT/BASIC,NORMAL,<19.938,11.8325,0.9185>,<0,1,0>,<19.938,11.8325,0.9185>,USE THEO=YES
              HIT/BASIC,NORMAL,<19.4205,11.8325,1.8495>,<0,1,0>,<19.4205,11.8325,1.8495>,USE THEO=YES
              HIT/BASIC,NORMAL,<18.0901,11.8325,1.8453>,<0,1,0>,<18.0901,11.8325,1.8453>,USE THEO=YES
              HIT/BASIC,NORMAL,<17.6086,11.8325,0.889>,<0,1,0>,<17.6086,11.8325,0.889>,USE THEO=YES
              HIT/BASIC,NORMAL,<17.6078,11.8325,0.2281>,<0,1,0>,<17.6078,11.8325,0.2281>,USE THEO=YES
            ENDMEAS/
PLN21      =FEAT/PLANE,CARTESIAN,OUTLINE
            THEO/<9.7648,11.7175,0.5554>,<0,1,0>
            ACTL/<9.7648,11.7175,0.5554>,<0,1,0>
            MEAS/PLANE,10
              MOVE/CLEARPLANE
              HIT/BASIC,NORMAL,<17.1484,11.7175,0.2286>,<0,1,0>,<17.1484,11.7175,0.2286>,USE THEO=YES
              HIT/BASIC,NORMAL,<17.1564,11.7175,0.887>,<0,1,0>,<17.1564,11.7175,0.887>,USE THEO=YES
              HIT/BASIC,NORMAL,<15.5107,11.7175,0.8727>,<0,1,0>,<15.5107,11.7175,0.8727>,USE THEO=YES
              HIT/BASIC,NORMAL,<13.259,11.7175,0.2243>,<0,1,0>,<13.259,11.7175,0.2243>,USE THEO=YES
              HIT/BASIC,NORMAL,<11.2633,11.7175,0.9053>,<0,1,0>,<11.2633,11.7175,0.9053>,USE THEO=YES
              HIT/BASIC,NORMAL,<9.1774,11.7175,0.2198>,<0,1,0>,<9.1774,11.7175,0.2198>,USE THEO=YES
              HIT/BASIC,NORMAL,<6.8362,11.7175,0.877>,<0,1,0>,<6.8362,11.7175,0.877>,USE THEO=YES
              HIT/BASIC,NORMAL,<4.1262,11.7175,0.2283>,<0,1,0>,<4.1262,11.7175,0.2283>,USE THEO=YES
              HIT/BASIC,NORMAL,<1.5944,11.7175,0.8751>,<0,1,0>,<1.5944,11.7175,0.8751>,USE THEO=YES
              HIT/BASIC,NORMAL,<1.5759,11.7175,0.2362>,<0,1,0>,<1.5759,11.7175,0.2362>,USE THEO=YES
            ENDMEAS/
PLN22      =FEAT/PLANE,CARTESIAN,OUTLINE
            THEO/<13.3175,14.4839,0.4631>,<0,1,0>
            ACTL/<13.3175,14.4839,0.4631>,<0,1,0>
            MEAS/PLANE,12
              MOVE/CLEARPLANE
              HIT/BASIC,NORMAL,<1.6111,14.4839,0.8846>,<0,1,0>,<1.6111,14.4839,0.8846>,USE THEO=YES
              HIT/BASIC,NORMAL,<1.5924,14.4839,0.0523>,<0,1,0>,<1.5924,14.4839,0.0523>,USE THEO=YES
              HIT/BASIC,NORMAL,<4.5721,14.4839,0.8675>,<0,1,0>,<4.5721,14.4839,0.8675>,USE THEO=YES
              HIT/BASIC,NORMAL,<6.7748,14.4839,0.0463>,<0,1,0>,<6.7748,14.4839,0.0463>,USE THEO=YES
              HIT/BASIC,NORMAL,<9.8363,14.4839,0.8698>,<0,1,0>,<9.8363,14.4839,0.8698>,USE THEO=YES
              HIT/BASIC,NORMAL,<12.3835,14.4839,0.0373>,<0,1,0>,<12.3835,14.4839,0.0373>,USE THEO=YES
              HIT/BASIC,NORMAL,<15.2595,14.4839,0.8848>,<0,1,0>,<15.2595,14.4839,0.8848>,USE THEO=YES
              HIT/BASIC,NORMAL,<17.6652,14.4839,0.0314>,<0,1,0>,<17.6652,14.4839,0.0314>,USE THEO=YES
              HIT/BASIC,NORMAL,<20.0667,14.4839,0.8888>,<0,1,0>,<20.0667,14.4839,0.8888>,USE THEO=YES
              HIT/BASIC,NORMAL,<21.6425,14.4839,0.0496>,<0,1,0>,<21.6425,14.4839,0.0496>,USE THEO=YES
              HIT/BASIC,NORMAL,<24.1926,14.4839,0.054>,<0,1,0>,<24.1926,14.4839,0.054>,USE THEO=YES
              HIT/BASIC,NORMAL,<24.2136,14.4839,0.8907>,<0,1,0>,<24.2136,14.4839,0.8907>,USE THEO=YES
            ENDMEAS/
PLN23      =FEAT/PLANE,CARTESIAN,OUTLINE
            THEO/<18.7563,14.4339,1.4644>,<0,1,0>
            ACTL/<18.7563,14.4339,1.4644>,<0,1,0>
            MEAS/PLANE,4
              MOVE/CLEARPLANE
              HIT/BASIC,NORMAL,<19.7382,14.4339,1.097>,<0,1,0>,<19.7382,14.4339,1.097>,USE THEO=YES
              HIT/BASIC,NORMAL,<19.4025,14.4339,1.8267>,<0,1,0>,<19.4025,14.4339,1.8267>,USE THEO=YES
              HIT/BASIC,NORMAL,<18.0996,14.4339,1.8249>,<0,1,0>,<18.0996,14.4339,1.8249>,USE THEO=YES
              HIT/BASIC,NORMAL,<17.7848,14.4339,1.109>,<0,1,0>,<17.7848,14.4339,1.109>,USE THEO=YES
            ENDMEAS/
            MOVE/CLEARPLANE
            TIP/T1A10B90, SHANKIJK=-0.1736, 0, 0.9848, ANGLE=90
PLN24      =FEAT/PLANE,CARTESIAN,OUTLINE
            THEO/<24.5011,17.2905,0.6887>,<-1,0,0>
            ACTL/<24.5011,17.2905,0.6887>,<-1,0,0>
            MEAS/PLANE,5
              MOVE/CLEARPLANE
              HIT/BASIC,NORMAL,<24.5011,14.8338,0.8836>,<-1,0,0>,<24.5011,14.8338,0.8836>,USE THEO=YES
              HIT/BASIC,NORMAL,<24.5011,14.8195,0.052>,<-1,0,0>,<24.5011,14.8195,0.052>,USE THEO=YES
              HIT/BASIC,NORMAL,<24.5011,17.2279,0.8765>,<-1,0,0>,<24.5011,17.2279,0.8765>,USE THEO=YES
              HIT/BASIC,NORMAL,<24.5011,19.7713,0.0665>,<-1,0,0>,<24.5011,19.7713,0.0665>,USE THEO=YES
              HIT/BASIC,NORMAL,<24.5011,19.7999,1.565>,<-1,0,0>,<24.5011,19.7999,1.565>,USE THEO=YES
            ENDMEAS/
            MOVE/CLEARPLANE
            TIP/T1A-10B0, SHANKIJK=0, -0.1736, 0.9848, ANGLE=0
PLN25      =FEAT/PLANE,CARTESIAN,OUTLINE
            THEO/<13.0024,20.1069,0.902>,<0,-1,0>
            ACTL/<13.0024,20.1069,0.902>,<0,-1,0>
            MEAS/PLANE,9
              MOVE/CLEARPLANE
              HIT/BASIC,NORMAL,<24.1067,20.1069,1.5505>,<0,-1,0>,<24.1067,20.1069,1.5505>,USE THEO=YES
              HIT/BASIC,NORMAL,<24.1654,20.1069,0.0774>,<0,-1,0>,<24.1654,20.1069,0.0774>,USE THEO=YES
              HIT/BASIC,NORMAL,<20.2011,20.1069,1.5766>,<0,-1,0>,<20.2011,20.1069,1.5766>,USE THEO=YES
              HIT/BASIC,NORMAL,<16.415,20.1069,0.0716>,<0,-1,0>,<16.415,20.1069,0.0716>,USE THEO=YES
              HIT/BASIC,NORMAL,<13.3092,20.1069,1.572>,<0,-1,0>,<13.3092,20.1069,1.572>,USE THEO=YES
              HIT/BASIC,NORMAL,<9.4845,20.1069,0.0504>,<0,-1,0>,<9.4845,20.1069,0.0504>,USE THEO=YES
              HIT/BASIC,NORMAL,<6.1186,20.1069,1.5859>,<0,-1,0>,<6.1186,20.1069,1.5859>,USE THEO=YES
              HIT/BASIC,NORMAL,<1.621,20.1069,0.0692>,<0,-1,0>,<1.621,20.1069,0.0692>,USE THEO=YES
              HIT/BASIC,NORMAL,<1.6001,20.1069,1.564>,<0,-1,0>,<1.6001,20.1069,1.564>,USE THEO=YES
            ENDMEAS/
PLN26      =FEAT/PLANE,CARTESIAN,OUTLINE
            THEO/<14.3019,26.0815,0.8364>,<0,-1,0>
            ACTL/<14.3019,26.0815,0.8364>,<0,-1,0>
            MEAS/PLANE,12
              MOVE/CLEARPLANE
              HIT/BASIC,NORMAL,<1.5649,26.0815,1.056>,<0,-1,0>,<1.5649,26.0815,1.056>,USE THEO=YES
              HIT/BASIC,NORMAL,<3.6671,26.0815,0.775>,<0,-1,0>,<3.6671,26.0815,0.775>,USE THEO=YES
              HIT/BASIC,NORMAL,<5.9059,26.0815,1.0726>,<0,-1,0>,<5.9059,26.0815,1.0726>,USE THEO=YES
              HIT/BASIC,NORMAL,<7.8737,26.0815,0.7795>,<0,-1,0>,<7.8737,26.0815,0.7795>,USE THEO=YES
              HIT/BASIC,NORMAL,<10.31,26.0815,1.0788>,<0,-1,0>,<10.31,26.0815,1.0788>,USE THEO=YES
              HIT/BASIC,NORMAL,<12.7747,26.0815,0.7794>,<0,-1,0>,<12.7747,26.0815,0.7794>,USE THEO=YES
              MOVE/POINT,NORMAL,<13.3913,25.8507,1.6>
              MOVE/POINT,NORMAL,<14.2793,25.8509,1.6>
              HIT/BASIC,NORMAL,<15.3337,26.0815,1.0588>,<0,-1,0>,<15.3337,26.0815,1.0588>,USE THEO=YES
              HIT/BASIC,NORMAL,<18.1355,26.0815,0.7774>,<0,-1,0>,<18.1355,26.0815,0.7774>,USE THEO=YES
              HIT/BASIC,NORMAL,<21.4959,26.0815,1.0497>,<0,-1,0>,<21.4959,26.0815,1.0497>,USE THEO=YES
              HIT/BASIC,NORMAL,<24.2707,26.0815,0.8126>,<0,-1,0>,<24.2707,26.0815,0.8126>,USE THEO=YES
              HIT/BASIC,NORMAL,<25.8482,26.0815,0.5006>,<0,-1,0>,<25.8482,26.0815,0.5006>,USE THEO=YES
              HIT/BASIC,NORMAL,<24.4424,26.0815,0.2957>,<0,-1,0>,<24.4424,26.0815,0.2957>,USE THEO=YES
            ENDMEAS/
PLN27      =FEAT/PLANE,CARTESIAN,OUTLINE
            THEO/<13.2075,25.8859,0.3087>,<0,-1,0>
            ACTL/<13.2075,25.8859,0.3087>,<0,-1,0>
            MEAS/PLANE,12
              MOVE/CLEARPLANE
              HIT/BASIC,NORMAL,<24.159,25.8859,0.0703>,<0,-1,0>,<24.159,25.8859,0.0703>,USE THEO=YES
              HIT/BASIC,NORMAL,<24.0375,25.8859,0.5869>,<0,-1,0>,<24.0375,25.8859,0.5869>,USE THEO=YES
              HIT/BASIC,NORMAL,<21.9945,25.8859,0.0213>,<0,-1,0>,<21.9945,25.8859,0.0213>,USE THEO=YES
              HIT/BASIC,NORMAL,<19.5602,25.8859,0.5783>,<0,-1,0>,<19.5602,25.8859,0.5783>,USE THEO=YES
              HIT/BASIC,NORMAL,<17.0761,25.8859,0.0451>,<0,-1,0>,<17.0761,25.8859,0.0451>,USE THEO=YES
              HIT/BASIC,NORMAL,<14.7986,25.8859,0.5488>,<0,-1,0>,<14.7986,25.8859,0.5488>,USE THEO=YES
              MOVE/POINT,NORMAL,<14.2238,23.7,0.4193>
              MOVE/POINT,NORMAL,<13.0408,23.7,0.1518>
              HIT/BASIC,NORMAL,<12.4295,25.8859,0.0242>,<0,-1,0>,<12.4295,25.8859,0.0242>,USE THEO=YES
              HIT/BASIC,NORMAL,<9.9234,25.8859,0.5729>,<0,-1,0>,<9.9234,25.8859,0.5729>,USE THEO=YES
              HIT/BASIC,NORMAL,<7.1634,25.8859,0.0402>,<0,-1,0>,<7.1634,25.8859,0.0402>,USE THEO=YES
              HIT/BASIC,NORMAL,<4.2338,25.8859,0.584>,<0,-1,0>,<4.2338,25.8859,0.584>,USE THEO=YES
              HIT/BASIC,NORMAL,<1.556,25.8859,0.0448>,<0,-1,0>,<1.556,25.8859,0.0448>,USE THEO=YES
              HIT/BASIC,NORMAL,<1.558,25.8859,0.587>,<0,-1,0>,<1.558,25.8859,0.587>,USE THEO=YES
            ENDMEAS/
            MOVE/CLEARPLANE
            TIP/T1A-10B90, SHANKIJK=0.1736, 0, 0.9848, ANGLE=90
PLN28      =FEAT/PLANE,CARTESIAN,OUTLINE
            THEO/<1.2587,23.118,0.7434>,<1,0,0>
            ACTL/<1.2587,23.118,0.7434>,<1,0,0>
            MEAS/PLANE,5
              MOVE/CLEARPLANE
              HIT/BASIC,NORMAL,<1.2587,25.728,1.0165>,<1,0,0>,<1.2587,25.728,1.0165>,USE THEO=YES
              HIT/BASIC,NORMAL,<1.2587,25.549,0.0443>,<1,0,0>,<1.2587,25.549,0.0443>,USE THEO=YES
              HIT/BASIC,NORMAL,<1.2587,23.1596,1.0453>,<1,0,0>,<1.2587,23.1596,1.0453>,USE THEO=YES
              HIT/BASIC,NORMAL,<1.2587,20.5887,0.0584>,<1,0,0>,<1.2587,20.5887,0.0584>,USE THEO=YES
              HIT/BASIC,NORMAL,<1.2587,20.5648,1.5525>,<1,0,0>,<1.2587,20.5648,1.5525>,USE THEO=YES
            ENDMEAS/
            MOVE/CLEARPLANE
            TIP/T1A10B0, SHANKIJK=0, 0.1736, 0.9848, ANGLE=0
PLN29      =FEAT/PLANE,CARTESIAN,OUTLINE
            THEO/<13.235,20.2629,0.9115>,<0,1,0>
            ACTL/<13.235,20.2629,0.9115>,<0,1,0>
            MEAS/PLANE,9
              MOVE/CLEARPLANE
              HIT/BASIC,NORMAL,<1.6419,20.2629,1.5687>,<0,1,0>,<1.6419,20.2629,1.5687>,USE THEO=YES
              HIT/BASIC,NORMAL,<1.6259,20.2629,0.0665>,<0,1,0>,<1.6259,20.2629,0.0665>,USE THEO=YES
              HIT/BASIC,NORMAL,<5.9074,20.2629,1.5814>,<0,1,0>,<5.9074,20.2629,1.5814>,USE THEO=YES
              HIT/BASIC,NORMAL,<9.3346,20.2629,0.0613>,<0,1,0>,<9.3346,20.2629,0.0613>,USE THEO=YES
              HIT/BASIC,NORMAL,<13.6107,20.2629,1.58>,<0,1,0>,<13.6107,20.2629,1.58>,USE THEO=YES
              HIT/BASIC,NORMAL,<17.5125,20.2629,0.0794>,<0,1,0>,<17.5125,20.2629,0.0794>,USE THEO=YES
              HIT/BASIC,NORMAL,<21.1635,20.2629,1.5941>,<0,1,0>,<21.1635,20.2629,1.5941>,USE THEO=YES
              HIT/BASIC,NORMAL,<24.1499,20.2629,0.0903>,<0,1,0>,<24.1499,20.2629,0.0903>,USE THEO=YES
              HIT/BASIC,NORMAL,<24.1688,20.2629,1.5814>,<0,1,0>,<24.1688,20.2629,1.5814>,USE THEO=YES
            ENDMEAS/
            MOVE/CLEARPLANE
PLN41      =FEAT/PLANE,CARTESIAN,OUTLINE
            THEO/<13.4029,26.1415,0.5646>,<0,1,0>
            ACTL/<13.4029,26.1415,0.5646>,<0,1,0>
            MEAS/PLANE,11
              MOVE/CLEARPLANE
              HIT/BASIC,NORMAL,<0.1493,26.1415,0.9888>,<0,1,0>,<0.1493,26.1415,0.9888>,USE THEO=YES
              HIT/BASIC,NORMAL,<0.1354,26.1415,0.2156>,<0,1,0>,<0.1354,26.1415,0.2156>,USE THEO=YES
              HIT/BASIC,NORMAL,<3.4971,26.1415,1.0241>,<0,1,0>,<3.4971,26.1415,1.0241>,USE THEO=YES
              HIT/BASIC,NORMAL,<6.7462,26.1415,0.2045>,<0,1,0>,<6.7462,26.1415,0.2045>,USE THEO=YES
              HIT/BASIC,NORMAL,<10.296,26.1415,1.0029>,<0,1,0>,<10.296,26.1415,1.0029>,USE THEO=YES
              HIT/BASIC,NORMAL,<12.9887,26.1415,0.228>,<0,1,0>,<12.9887,26.1415,0.228>,USE THEO=YES
              MOVE/POINT,NORMAL,<13.5999,26.75,0.3433>
              MOVE/POINT,NORMAL,<14.0686,26.5,0.4296>
              HIT/BASIC,NORMAL,<17.0783,26.1415,0.9994>,<0,1,0>,<17.0783,26.1415,0.9994>,USE THEO=YES
              HIT/BASIC,NORMAL,<20.5307,26.1415,0.1886>,<0,1,0>,<20.5307,26.1415,0.1886>,USE THEO=YES
              MOVE/POINT,NORMAL,<22.3539,26.368,1.6>
              MOVE/POINT,NORMAL,<23.5696,26.3745,1.6>
              HIT/BASIC,NORMAL,<24.2751,26.1415,0.6914>,<0,1,0>,<24.2751,26.1415,0.6914>,USE THEO=YES
              HIT/BASIC,NORMAL,<25.8508,26.1415,0.5208>,<0,1,0>,<25.8508,26.1415,0.5208>,USE THEO=YES
              HIT/BASIC,NORMAL,<25.8843,26.1415,0.146>,<0,1,0>,<25.8843,26.1415,0.146>,USE THEO=YES
            ENDMEAS/
            MOVE/CLEARPLANE
            TIP/T1A10B90, SHANKIJK=-0.1736, 0, 0.9848, ANGLE=90
            CLEARP/ZPLUS,2,ZPLUS,2,OFF
PLN30      =FEAT/PLANE,CARTESIAN,OUTLINE
            THEO/<24.5011,23.0096,0.5482>,<-1,0,0>
            ACTL/<24.5011,23.0096,0.5482>,<-1,0,0>
            MEAS/PLANE,6
              HIT/BASIC,NORMAL,<24.5011,20.5982,1.4588>,<-1,0,0>,<24.5011,20.5982,1.4588>,USE THEO=YES
              HIT/BASIC,NORMAL,<24.5011,20.6013,0.0742>,<-1,0,0>,<24.5011,20.6013,0.0742>,USE THEO=YES
              HIT/BASIC,NORMAL,<24.5011,22.5138,0.8487>,<-1,0,0>,<24.5011,22.5138,0.8487>,USE THEO=YES
              HIT/BASIC,NORMAL,<24.5011,24.34,0.7756>,<-1,0,0>,<24.5011,24.34,0.7756>,USE THEO=YES
              HIT/BASIC,NORMAL,<24.5011,24.47,0.0773>,<-1,0,0>,<24.5011,24.47,0.0773>,USE THEO=YES
              HIT/BASIC,NORMAL,<24.5011,25.534,0.0548>,<-1,0,0>,<24.5011,25.534,0.0548>,USE THEO=YES
            ENDMEAS/
            MOVE/POINT,NORMAL,<24.25,25.5,0.25>
PLN31      =FEAT/PLANE,CARTESIAN,OUTLINE
            THEO/<27.1489,22.0985,0.4615>,<-0.9542031,-0.2991597,0>
            ACTL/<27.1489,22.0985,0.4615>,<-0.9542031,-0.2991597,0>
            MEAS/PLANE,5
              HIT/BASIC,NORMAL,<26.4575,24.3036,0.2821>,<-0.9542031,-0.2991597,0>,<26.4575,24.3036,0.2821>,USE THEO=YES
              HIT/BASIC,NORMAL,<26.4798,24.2325,0.7148>,<-0.9542031,-0.2991597,0>,<26.4798,24.2325,0.7148>,USE THEO=YES
              HIT/BASIC,NORMAL,<27.1251,22.1744,0.278>,<-0.9542031,-0.2991597,0>,<27.1251,22.1744,0.278>,USE THEO=YES
              HIT/BASIC,NORMAL,<27.8377,19.9014,0.7374>,<-0.9542031,-0.2991597,0>,<27.8377,19.9014,0.7374>,USE THEO=YES
              HIT/BASIC,NORMAL,<27.8443,19.8804,0.2954>,<-0.9542031,-0.2991597,0>,<27.8443,19.8804,0.2954>,USE THEO=YES
            ENDMEAS/
PLN32      =FEAT/PLANE,CARTESIAN,OUTLINE
            THEO/<27.91,13.2435,0.5103>,<-1,0,0>
            ACTL/<27.91,13.2435,0.5103>,<-1,0,0>
            MEAS/PLANE,8
              HIT/BASIC,NORMAL,<27.91,19.4431,0.7447>,<-1,0,0>,<27.91,19.4431,0.7447>,USE THEO=YES
              HIT/BASIC,NORMAL,<27.91,19.4657,0.2943>,<-1,0,0>,<27.91,19.4657,0.2943>,USE THEO=YES
              HIT/BASIC,NORMAL,<27.91,16.8924,0.7253>,<-1,0,0>,<27.91,16.8924,0.7253>,USE THEO=YES
              HIT/BASIC,NORMAL,<27.91,14.5679,0.26>,<-1,0,0>,<27.91,14.5679,0.26>,USE THEO=YES
              HIT/BASIC,NORMAL,<27.91,12.2922,0.7521>,<-1,0,0>,<27.91,12.2922,0.7521>,USE THEO=YES
              HIT/BASIC,NORMAL,<27.91,9.9166,0.2777>,<-1,0,0>,<27.91,9.9166,0.2777>,USE THEO=YES
              HIT/BASIC,NORMAL,<27.91,6.6886,0.7425>,<-1,0,0>,<27.91,6.6886,0.7425>,USE THEO=YES
              HIT/BASIC,NORMAL,<27.91,6.6816,0.2856>,<-1,0,0>,<27.91,6.6816,0.2856>,USE THEO=YES
            ENDMEAS/
PLN33      =FEAT/PLANE,CARTESIAN,OUTLINE
            THEO/<27.1764,4.1308,0.5481>,<-0.9542031,0.2991597,0>
            ACTL/<27.1764,4.1308,0.5481>,<-0.9542031,0.2991597,0>
            MEAS/PLANE,5
              HIT/BASIC,NORMAL,<27.8547,6.2944,0.7646>,<-0.9542031,0.2991597,0>,<27.8547,6.2944,0.7646>,USE THEO=YES
              HIT/BASIC,NORMAL,<27.855,6.2952,0.2692>,<-0.9542031,0.2991597,0>,<27.855,6.2952,0.2692>,USE THEO=YES
              HIT/BASIC,NORMAL,<27.2207,4.2722,0.7319>,<-0.9542031,0.2991597,0>,<27.2207,4.2722,0.7319>,USE THEO=YES
              HIT/BASIC,NORMAL,<26.4668,1.8675,0.273>,<-0.9542031,0.2991597,0>,<26.4668,1.8675,0.273>,USE THEO=YES
              HIT/BASIC,NORMAL,<26.4848,1.9248,0.7018>,<-0.9542031,0.2991597,0>,<26.4848,1.9248,0.7018>,USE THEO=YES
            ENDMEAS/
            MOVE/POINT,NORMAL,<26,1.9,2>
            TIP/T1A-10B90, SHANKIJK=0.1736, 0, 0.9848, ANGLE=90
            MOVE/POINT,NORMAL,<25,1.9,2>
PLN34      =FEAT/PLANE,CARTESIAN,OUTLINE
            THEO/<24.5711,13.163,0.715>,<1,0,0>
            ACTL/<24.5711,13.163,0.715>,<1,0,0>
            MEAS/PLANE,15
              HIT/BASIC,NORMAL,<24.5711,1.7934,0.3202>,<1,0,0>,<24.5711,1.7934,0.3202>,USE THEO=YES
              HIT/BASIC,NORMAL,<24.5711,1.8231,0.8576>,<1,0,0>,<24.5711,1.8231,0.8576>,USE THEO=YES
              HIT/BASIC,NORMAL,<24.5711,3.6298,0.2818>,<1,0,0>,<24.5711,3.6298,0.2818>,USE THEO=YES
              HIT/BASIC,NORMAL,<24.5711,4.9705,0.8793>,<1,0,0>,<24.5711,4.9705,0.8793>,USE THEO=YES
              HIT/BASIC,NORMAL,<24.5711,5.9263,1.5601>,<1,0,0>,<24.5711,5.9263,1.5601>,USE THEO=YES
              HIT/BASIC,NORMAL,<24.5711,7.111,0.8179>,<1,0,0>,<24.5711,7.111,0.8179>,USE THEO=YES
              HIT/BASIC,NORMAL,<24.5711,9.92,0.2754>,<1,0,0>,<24.5711,9.92,0.2754>,USE THEO=YES
              HIT/BASIC,NORMAL,<24.5711,13.157,0.857>,<1,0,0>,<24.5711,13.157,0.857>,USE THEO=YES
              HIT/BASIC,NORMAL,<24.5711,16.814,0.2815>,<1,0,0>,<24.5711,16.814,0.2815>,USE THEO=YES
              HIT/BASIC,NORMAL,<24.5711,19.0761,0.8416>,<1,0,0>,<24.5711,19.0761,0.8416>,USE THEO=YES
              HIT/BASIC,NORMAL,<24.5711,20.1406,1.4992>,<1,0,0>,<24.5711,20.1406,1.4992>,USE THEO=YES
              HIT/BASIC,NORMAL,<24.5711,21.3812,0.8059>,<1,0,0>,<24.5711,21.3812,0.8059>,USE THEO=YES
              HIT/BASIC,NORMAL,<24.5711,23.0081,0.3137>,<1,0,0>,<24.5711,23.0081,0.3137>,USE THEO=YES
              HIT/BASIC,NORMAL,<24.5711,24.3321,0.8282>,<1,0,0>,<24.5711,24.3321,0.8282>,USE THEO=YES
              HIT/BASIC,NORMAL,<24.5711,24.3617,0.306>,<1,0,0>,<24.5711,24.3617,0.306>,USE THEO=YES
            ENDMEAS/
PLN35      =FEAT/PLANE,CARTESIAN,OUTLINE
            THEO/<26.8526,23.2442,0.2882>,<0.9542031,0.2991597,0>
            ACTL/<26.8526,23.2442,0.2882>,<0.9542031,0.2991597,0>
            MEAS/PLANE,7
              HIT/BASIC,NORMAL,<25.9577,26.0985,0.3701>,<0.9542031,0.2991597,0>,<25.9577,26.0985,0.3701>,USE THEO=YES
              HIT/BASIC,NORMAL,<25.9645,26.0768,0.0706>,<0.9542031,0.2991597,0>,<25.9645,26.0768,0.0706>,USE THEO=YES
              HIT/BASIC,NORMAL,<26.5242,24.2915,0.0422>,<0.9542031,0.2991597,0>,<26.5242,24.2915,0.0422>,USE THEO=YES
              HIT/BASIC,NORMAL,<26.5473,24.2177,0.7118>,<0.9542031,0.2991597,0>,<26.5473,24.2177,0.7118>,USE THEO=YES
              HIT/BASIC,NORMAL,<27.182,22.1934,0.0429>,<0.9542031,0.2991597,0>,<27.182,22.1934,0.0429>,USE THEO=YES
              HIT/BASIC,NORMAL,<27.9004,19.9019,0.7258>,<0.9542031,0.2991597,0>,<27.9004,19.9019,0.7258>,USE THEO=YES
              HIT/BASIC,NORMAL,<27.8918,19.9293,0.054>,<0.9542031,0.2991597,0>,<27.8918,19.9293,0.054>,USE THEO=YES
            ENDMEAS/
            MOVE/POINT,NORMAL,<28,20,2>
            TIP/T1A0B0, SHANKIJK=0, 0, 1, ANGLE=0
            MOVE/POINT,NORMAL,<28,20,2>
PLN36      =FEAT/PLANE,CARTESIAN,OUTLINE
            THEO/<27.97,13.0738,0.429>,<1,0,0>
            ACTL/<27.97,13.0738,0.429>,<1,0,0>
            MEAS/PLANE,8
              HIT/BASIC,NORMAL,<27.97,19.4405,0.1034>,<1,0,0>,<27.97,19.4405,0.1034>,USE THEO=YES
              HIT/BASIC,NORMAL,<27.97,19.4421,0.7574>,<1,0,0>,<27.97,19.4421,0.7574>,USE THEO=YES
              MOVE/POINT,NORMAL,<28.1928,19.128,1.6>
              MOVE/POINT,NORMAL,<28.1984,17.7585,1.6>
              HIT/BASIC,NORMAL,<27.97,16.754,0.7579>,<1,0,0>,<27.97,16.754,0.7579>,USE THEO=YES
              HIT/BASIC,NORMAL,<27.97,14.434,0.1047>,<1,0,0>,<27.97,14.434,0.1047>,USE THEO=YES
              HIT/BASIC,NORMAL,<27.97,11.7192,0.7215>,<1,0,0>,<27.97,11.7192,0.7215>,USE THEO=YES
              HIT/BASIC,NORMAL,<27.97,9.3588,0.1241>,<1,0,0>,<27.97,9.3588,0.1241>,USE THEO=YES
              MOVE/POINT,NORMAL,<28.1962,8.8931,1.6>
              MOVE/POINT,NORMAL,<28.1948,7.3754,1.6>
              HIT/BASIC,NORMAL,<27.97,6.7487,0.7329>,<1,0,0>,<27.97,6.7487,0.7329>,USE THEO=YES
              HIT/BASIC,NORMAL,<27.97,6.6932,0.1298>,<1,0,0>,<27.97,6.6932,0.1298>,USE THEO=YES
            ENDMEAS/
PLN37      =FEAT/PLANE,CARTESIAN,OUTLINE
            THEO/<26.8955,3.0343,0.3725>,<0.9542031,-0.2991597,0>
            ACTL/<26.8955,3.0343,0.3725>,<0.9542031,-0.2991597,0>
            MEAS/PLANE,8
              HIT/BASIC,NORMAL,<27.9021,6.245,0.1409>,<0.9542031,-0.2991597,0>,<27.9021,6.245,0.1409>,USE THEO=YES
              HIT/BASIC,NORMAL,<27.9015,6.2429,0.7645>,<0.9542031,-0.2991597,0>,<27.9015,6.2429,0.7645>,USE THEO=YES
              HIT/BASIC,NORMAL,<27.4128,4.6844,0.1397>,<0.9542031,-0.2991597,0>,<27.4128,4.6844,0.1397>,USE THEO=YES
              HIT/BASIC,NORMAL,<26.9941,3.3488,0.7325>,<0.9542031,-0.2991597,0>,<26.9941,3.3488,0.7325>,USE THEO=YES
              HIT/BASIC,NORMAL,<26.5404,1.9016,0.708>,<0.9542031,-0.2991597,0>,<26.5404,1.9016,0.708>,USE THEO=YES
              HIT/BASIC,NORMAL,<26.4912,1.7448,0.0621>,<0.9542031,-0.2991597,0>,<26.4912,1.7448,0.0621>,USE THEO=YES
              HIT/BASIC,NORMAL,<25.9699,0.0819,0.0697>,<0.9542031,-0.2991597,0>,<25.9699,0.0819,0.0697>,USE THEO=YES
              HIT/BASIC,NORMAL,<25.952,0.0248,0.3628>,<0.9542031,-0.2991597,0>,<25.952,0.0248,0.3628>,USE THEO=YES
            ENDMEAS/
PLN38      =FEAT/PLANE,CARTESIAN,OUTLINE
            THEO/<25.6877,13.0528,0.113>,<0,0,1>
            ACTL/<25.6877,13.0528,0.113>,<0,0,1>
            MEAS/PLANE,19
              HIT/BASIC,NORMAL,<25.9701,0.2536,0.113>,<0,0,1>,<25.9701,0.2536,0.113>,USE THEO=YES
              HIT/BASIC,NORMAL,<24.349,0.233,0.113>,<0,0,1>,<24.349,0.233,0.113>,USE THEO=YES
              HIT/BASIC,NORMAL,<24.5477,1.4865,0.113>,<0,0,1>,<24.5477,1.4865,0.113>,USE THEO=YES
              HIT/BASIC,NORMAL,<26.4013,1.6158,0.113>,<0,0,1>,<26.4013,1.6158,0.113>,USE THEO=YES
              HIT/BASIC,NORMAL,<24.7394,2.0515,0.113>,<0,0,1>,<24.7394,2.0515,0.113>,USE THEO=YES
              HIT/BASIC,NORMAL,<26.8816,3.7862,0.113>,<0,0,1>,<26.8816,3.7862,0.113>,USE THEO=YES
              HIT/BASIC,NORMAL,<24.7949,5.7786,0.113>,<0,0,1>,<24.7949,5.7786,0.113>,USE THEO=YES
              HIT/BASIC,NORMAL,<27.6897,6.5469,0.113>,<0,0,1>,<27.6897,6.5469,0.113>,USE THEO=YES
              HIT/BASIC,NORMAL,<24.7995,9.6428,0.113>,<0,0,1>,<24.7995,9.6428,0.113>,USE THEO=YES
              HIT/BASIC,NORMAL,<27.5922,13.2591,0.113>,<0,0,1>,<27.5922,13.2591,0.113>,USE THEO=YES
              HIT/BASIC,NORMAL,<24.823,17.164,0.113>,<0,0,1>,<24.823,17.164,0.113>,USE THEO=YES
              HIT/BASIC,NORMAL,<27.6878,19.5878,0.113>,<0,0,1>,<27.6878,19.5878,0.113>,USE THEO=YES
              HIT/BASIC,NORMAL,<24.7831,20.0299,0.113>,<0,0,1>,<24.7831,20.0299,0.113>,USE THEO=YES
              HIT/BASIC,NORMAL,<26.9394,22.1081,0.113>,<0,0,1>,<26.9394,22.1081,0.113>,USE THEO=YES
              HIT/BASIC,NORMAL,<24.7612,23.4671,0.113>,<0,0,1>,<24.7612,23.4671,0.113>,USE THEO=YES
              HIT/BASIC,NORMAL,<26.3178,24.5768,0.113>,<0,0,1>,<26.3178,24.5768,0.113>,USE THEO=YES
              HIT/BASIC,NORMAL,<24.6236,24.6762,0.113>,<0,0,1>,<24.6236,24.6762,0.113>,USE THEO=YES
              HIT/BASIC,NORMAL,<24.4027,25.907,0.113>,<0,0,1>,<24.4027,25.907,0.113>,USE THEO=YES
              HIT/BASIC,NORMAL,<25.9625,25.8324,0.113>,<0,0,1>,<25.9625,25.8324,0.113>,USE THEO=YES
            ENDMEAS/
            MOVE/POINT,NORMAL,<25.8,25.8,2>
            MOVE/POINT,NORMAL,<24.3,14,2>
PLN39      =FEAT/PLANE,CARTESIAN,OUTLINE
            THEO/<14.524,13.0719,0.06>,<0,0,1>
            ACTL/<14.524,13.0719,0.06>,<0,0,1>
            MEAS/PLANE,13
              HIT/BASIC,NORMAL,<24.2951,14.2132,0.06>,<0,0,1>,<24.2951,14.2132,0.06>,USE THEO=YES
              HIT/BASIC,NORMAL,<24.2877,11.9359,0.06>,<0,0,1>,<24.2877,11.9359,0.06>,USE THEO=YES
              HIT/BASIC,NORMAL,<20.354,11.9498,0.06>,<0,0,1>,<20.354,11.9498,0.06>,USE THEO=YES
              HIT/BASIC,NORMAL,<20.3459,14.2036,0.06>,<0,0,1>,<20.3459,14.2036,0.06>,USE THEO=YES
              HIT/BASIC,NORMAL,<17.2517,11.939,0.06>,<0,0,1>,<17.2517,11.939,0.06>,USE THEO=YES
              HIT/BASIC,NORMAL,<17.2858,14.1553,0.06>,<0,0,1>,<17.2858,14.1553,0.06>,USE THEO=YES
              HIT/BASIC,NORMAL,<14.6086,13.1337,0.06>,<0,0,1>,<14.6086,13.1337,0.06>,USE THEO=YES
              HIT/BASIC,NORMAL,<12.2368,14.1393,0.06>,<0,0,1>,<12.2368,14.1393,0.06>,USE THEO=YES
              HIT/BASIC,NORMAL,<12.1916,11.9791,0.06>,<0,0,1>,<12.1916,11.9791,0.06>,USE THEO=YES
              HIT/BASIC,NORMAL,<8.4684,14.2318,0.06>,<0,0,1>,<8.4684,14.2318,0.06>,USE THEO=YES
              HIT/BASIC,NORMAL,<8.4277,11.9176,0.06>,<0,0,1>,<8.4277,11.9176,0.06>,USE THEO=YES
              HIT/BASIC,NORMAL,<4.5235,14.2208,0.06>,<0,0,1>,<4.5235,14.2208,0.06>,USE THEO=YES
              HIT/BASIC,NORMAL,<4.5358,11.9154,0.06>,<0,0,1>,<4.5358,11.9154,0.06>,USE THEO=YES
            ENDMEAS/
PLN40      =FEAT/PLANE,CARTESIAN,OUTLINE
            THEO/<1.6838,13.0558,0.06>,<0,0,1>
            ACTL/<1.6838,13.0558,0.06>,<0,0,1>
            MEAS/PLANE,4
              HIT/BASIC,NORMAL,<1.8704,14.225,0.06>,<0,0,1>,<1.8704,14.225,0.06>,USE THEO=YES
              HIT/BASIC,NORMAL,<1.4911,14.2074,0.06>,<0,0,1>,<1.4911,14.2074,0.06>,USE THEO=YES
              HIT/BASIC,NORMAL,<1.4484,11.9085,0.06>,<0,0,1>,<1.4484,11.9085,0.06>,USE THEO=YES
              HIT/BASIC,NORMAL,<1.9254,11.8822,0.06>,<0,0,1>,<1.9254,11.8822,0.06>,USE THEO=YES
            ENDMEAS/
N2         =FEAT/CONTACT/CIRCLE/DEFAULT,CARTESIAN,IN,LEAST_SQR
            THEO/<1.6091,13.0713,0.06>,<0,0,1>,0.2235
            ACTL/<1.6091,13.0713,0.06>,<0,0,1>,0.2235
            TARG/<1.6091,13.0713,0.06>,<0,0,1>
            START ANG=0,END ANG=360
            ANGLE VEC=<1,0,0>
            DIRECTION=CCW
            SHOW FEATURE PARAMETERS=NO
            SHOW CONTACT PARAMETERS=YES
              NUMHITS=5,DEPTH=0.03,PITCH=0
              SAMPLE METHOD=SAMPLE_FEATURE
              SAMPLE FEATURE=NONE
              AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              FIND HOLE=DISABLED,ONERROR=NO,READ POS=NO
            SHOW HITS=NO
P1         =FEAT/CONTACT/SQUARE SLOT/DEFAULT,CARTESIAN,IN
            THEO/<3.1787,13.0707,0.06>,<0,0,1>,<1,0,0>,2.5,2.6
            ACTL/<3.1787,13.0707,0.06>,<0,0,1>,<1,0,0>,2.5,2.6
            TARG/<3.1787,13.0707,0.06>,<0,0,1>,<1,0,0>
            MEAS WIDTH=NO,RADIUS=0.25
            SHOW FEATURE PARAMETERS=NO
            SHOW CONTACT PARAMETERS=YES
              DEPTH=0.025
              SAMPLE METHOD=SAMPLE_FEATURE
              SAMPLE FEATURE=NONE
              AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              FIND HOLE=DISABLED,ONERROR=NO,READ POS=NO
            SHOW HITS=NO
N1         =FEAT/CONTACT/CIRCLE/DEFAULT,CARTESIAN,IN,LEAST_SQR
            THEO/<4.8291,13.0713,0.06>,<0,0,1>,0.2235
            ACTL/<4.8291,13.0713,0.06>,<0,0,1>,0.2235
            TARG/<4.8291,13.0713,0.06>,<0,0,1>
            START ANG=0,END ANG=360
            ANGLE VEC=<1,0,0>
            DIRECTION=CCW
            SHOW FEATURE PARAMETERS=NO
            SHOW CONTACT PARAMETERS=YES
              NUMHITS=5,DEPTH=0.03,PITCH=0
              SAMPLE METHOD=SAMPLE_FEATURE
              SAMPLE FEATURE=NONE
              AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              FIND HOLE=DISABLED,ONERROR=NO,READ POS=NO
            SHOW HITS=NO
B14        =FEAT/CONTACT/CIRCLE/DEFAULT,CARTESIAN,IN,LEAST_SQR
            THEO/<5.7001,14.0107,0.06>,<0,0,1>,0.2
            ACTL/<5.7001,14.0107,0.06>,<0,0,1>,0.2
            TARG/<5.7001,14.0107,0.06>,<0,0,1>
            START ANG=0,END ANG=360
            ANGLE VEC=<1,0,0>
            DIRECTION=CCW
            SHOW FEATURE PARAMETERS=NO
            SHOW CONTACT PARAMETERS=YES
              NUMHITS=5,DEPTH=0.03,PITCH=0
              SAMPLE METHOD=SAMPLE_FEATURE
              SAMPLE FEATURE=NONE
              AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              FIND HOLE=DISABLED,ONERROR=NO,READ POS=NO
            SHOW HITS=NO
M2B        =FEAT/CONTACT/CIRCLE/DEFAULT,CARTESIAN,IN,LEAST_SQR
            THEO/<5.7701,13.0707,0.06>,<0,0,1>,0.199
            ACTL/<5.7701,13.0707,0.06>,<0,0,1>,0.199
            TARG/<5.7701,13.0707,0.06>,<0,0,1>
            START ANG=89.9998,END ANG=270
            ANGLE VEC=<1,0,0>
            DIRECTION=CCW
            SHOW FEATURE PARAMETERS=NO
            SHOW CONTACT PARAMETERS=YES
              NUMHITS=5,DEPTH=0.03,PITCH=0
              SAMPLE METHOD=SAMPLE_FEATURE
              SAMPLE FEATURE=NONE
              AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              FIND HOLE=DISABLED,ONERROR=NO,READ POS=NO
            SHOW HITS=NO
M2         =FEAT/CONTACT/CIRCLE/DEFAULT,CARTESIAN,IN,LEAST_SQR
            THEO/<6.2701,13.0707,0.06>,<0,0,1>,0.39
            ACTL/<6.2701,13.0707,0.06>,<0,0,1>,0.39
            TARG/<6.2701,13.0707,0.06>,<0,0,1>
            START ANG=229.4,END ANG=491.3
            ANGLE VEC=<1,0,0>
            DIRECTION=CCW
            SHOW FEATURE PARAMETERS=NO
            SHOW CONTACT PARAMETERS=YES
              NUMHITS=5,DEPTH=0.03,PITCH=0
              SAMPLE METHOD=SAMPLE_FEATURE
              SAMPLE FEATURE=NONE
              AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              FIND HOLE=DISABLED,ONERROR=NO,READ POS=NO
            SHOW HITS=NO
M1B        =FEAT/CONTACT/CIRCLE/DEFAULT,CARTESIAN,IN,LEAST_SQR
            THEO/<7.9501,13.0707,0.06>,<0,0,1>,0.199
            ACTL/<7.9501,13.0707,0.06>,<0,0,1>,0.199
            TARG/<7.9501,13.0707,0.06>,<0,0,1>
            START ANG=89.9998,END ANG=270
            ANGLE VEC=<1,0,0>
            DIRECTION=CCW
            SHOW FEATURE PARAMETERS=NO
            SHOW CONTACT PARAMETERS=YES
              NUMHITS=5,DEPTH=0.03,PITCH=0
              SAMPLE METHOD=SAMPLE_FEATURE
              SAMPLE FEATURE=NONE
              AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              FIND HOLE=DISABLED,ONERROR=NO,READ POS=NO
            SHOW HITS=NO
M1         =FEAT/CONTACT/CIRCLE/DEFAULT,CARTESIAN,IN,LEAST_SQR
            THEO/<8.4501,13.0707,0.06>,<0,0,1>,0.39
            ACTL/<8.4501,13.0707,0.06>,<0,0,1>,0.39
            TARG/<8.4501,13.0707,0.06>,<0,0,1>
            START ANG=226.1,END ANG=497.3
            ANGLE VEC=<1,0,0>
            DIRECTION=CCW
            SHOW FEATURE PARAMETERS=NO
            SHOW CONTACT PARAMETERS=YES
              NUMHITS=5,DEPTH=0.03,PITCH=0
              SAMPLE METHOD=SAMPLE_FEATURE
              SAMPLE FEATURE=NONE
              AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              FIND HOLE=DISABLED,ONERROR=NO,READ POS=NO
            SHOW HITS=NO
B13        =FEAT/CONTACT/CIRCLE/DEFAULT,CARTESIAN,IN,LEAST_SQR
            THEO/<8.9401,12.2807,0.06>,<0,0,1>,0.2
            ACTL/<8.9401,12.2807,0.06>,<0,0,1>,0.2
            TARG/<8.9401,12.2807,0.06>,<0,0,1>
            START ANG=0,END ANG=360
            ANGLE VEC=<1,0,0>
            DIRECTION=CCW
            SHOW FEATURE PARAMETERS=NO
            SHOW CONTACT PARAMETERS=YES
              NUMHITS=5,DEPTH=0.03,PITCH=0
              SAMPLE METHOD=SAMPLE_FEATURE
              SAMPLE FEATURE=NONE
              AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              FIND HOLE=DISABLED,ONERROR=NO,READ POS=NO
            SHOW HITS=NO
G6         =FEAT/CONTACT/SQUARE SLOT/DEFAULT,CARTESIAN,IN
            THEO/<9.9887,13.0707,0.06>,<0,0,1>,<0,-1,0>,0.44,0.94
            ACTL/<9.9887,13.0707,0.06>,<0,0,1>,<0,-1,0>,0.44,0.94
            TARG/<9.9887,13.0707,0.06>,<0,0,1>,<0,-1,0>
            MEAS WIDTH=NO,RADIUS=0.0689
            SHOW FEATURE PARAMETERS=NO
            SHOW CONTACT PARAMETERS=YES
              DEPTH=0.02
              SAMPLE METHOD=SAMPLE_FEATURE
              SAMPLE FEATURE=NONE
              AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              FIND HOLE=DISABLED,ONERROR=NO,READ POS=NO
            SHOW HITS=NO
L1         =FEAT/CONTACT/SQUARE SLOT/DEFAULT,CARTESIAN,IN
            THEO/<11.18,13.0707,0.06>,<0,0,1>,<0,1,0>,0.44,1.94
            ACTL/<11.18,13.0707,0.06>,<0,0,1>,<0,1,0>,0.44,1.94
            TARG/<11.18,13.0707,0.06>,<0,0,1>,<0,1,0>
            MEAS WIDTH=NO,RADIUS=0.207
            SHOW FEATURE PARAMETERS=NO
            SHOW CONTACT PARAMETERS=YES
              DEPTH=0.02
              SAMPLE METHOD=SAMPLE_FEATURE
              SAMPLE FEATURE=NONE
              AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              FIND HOLE=DISABLED,ONERROR=NO,READ POS=NO
            SHOW HITS=NO
A18        =FEAT/CONTACT/CIRCLE/DEFAULT,CARTESIAN,IN,LEAST_SQR
            THEO/<12.2,13.7207,0.06>,<0,0,1>,0.48
            ACTL/<12.2,13.7207,0.06>,<0,0,1>,0.48
            TARG/<12.2,13.7207,0.06>,<0,0,1>
            START ANG=29.5,END ANG=331.7
            ANGLE VEC=<1,0,0>
            DIRECTION=CCW
            SHOW FEATURE PARAMETERS=NO
            SHOW CONTACT PARAMETERS=YES
              NUMHITS=5,DEPTH=0.03,PITCH=0
              SAMPLE METHOD=SAMPLE_FEATURE
              SAMPLE FEATURE=NONE
              AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              FIND HOLE=DISABLED,ONERROR=NO,READ POS=NO
            SHOW HITS=NO
A18B       =FEAT/CONTACT/CIRCLE/DEFAULT,CARTESIAN,IN,LEAST_SQR
            THEO/<12.57,13.7207,0.06>,<0,0,1>,0.128
            ACTL/<12.57,13.7207,0.06>,<0,0,1>,0.128
            TARG/<12.57,13.7207,0.06>,<0,0,1>
            START ANG=270,END ANG=450
            ANGLE VEC=<1,0,0>
            DIRECTION=CCW
            SHOW FEATURE PARAMETERS=NO
            SHOW CONTACT PARAMETERS=YES
              NUMHITS=5,DEPTH=0.03,PITCH=0
              SAMPLE METHOD=SAMPLE_FEATURE
              SAMPLE FEATURE=NONE
              AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              FIND HOLE=DISABLED,ONERROR=NO,READ POS=NO
            SHOW HITS=NO
A19        =FEAT/CONTACT/CIRCLE/DEFAULT,CARTESIAN,IN,LEAST_SQR
            THEO/<12.2,12.4207,0.06>,<0,0,1>,0.48
            ACTL/<12.2,12.4207,0.06>,<0,0,1>,0.48
            TARG/<12.2,12.4207,0.06>,<0,0,1>
            START ANG=28.3,END ANG=330.2
            ANGLE VEC=<1,0,0>
            DIRECTION=CCW
            SHOW FEATURE PARAMETERS=NO
            SHOW CONTACT PARAMETERS=YES
              NUMHITS=5,DEPTH=0.03,PITCH=0
              SAMPLE METHOD=SAMPLE_FEATURE
              SAMPLE FEATURE=NONE
              AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              FIND HOLE=DISABLED,ONERROR=NO,READ POS=NO
            SHOW HITS=NO
A19B       =FEAT/CONTACT/CIRCLE/DEFAULT,CARTESIAN,IN,LEAST_SQR
            THEO/<12.57,12.4207,0.06>,<0,0,1>,0.128
            ACTL/<12.57,12.4207,0.06>,<0,0,1>,0.128
            TARG/<12.57,12.4207,0.06>,<0,0,1>
            START ANG=274.4,END ANG=439.3
            ANGLE VEC=<1,0,0>
            DIRECTION=CCW
            SHOW FEATURE PARAMETERS=NO
            SHOW CONTACT PARAMETERS=YES
              NUMHITS=5,DEPTH=0.02,PITCH=0
              SAMPLE METHOD=SAMPLE_FEATURE
              SAMPLE FEATURE=NONE
              AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              FIND HOLE=DISABLED,ONERROR=NO,READ POS=NO
            SHOW HITS=NO
G4         =FEAT/CONTACT/SQUARE SLOT/DEFAULT,CARTESIAN,IN
            THEO/<13.2301,13.0707,0.06>,<0,0,1>,<0,-1,0>,0.44,0.94
            ACTL/<13.2301,13.0707,0.06>,<0,0,1>,<0,-1,0>,0.44,0.94
            TARG/<13.2301,13.0707,0.06>,<0,0,1>,<0,-1,0>
            MEAS WIDTH=NO,RADIUS=0.25
            SHOW FEATURE PARAMETERS=NO
            SHOW CONTACT PARAMETERS=YES
              DEPTH=0.02
              SAMPLE METHOD=SAMPLE_FEATURE
              SAMPLE FEATURE=NONE
              AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              FIND HOLE=DISABLED,ONERROR=NO,READ POS=NO
            SHOW HITS=NO
CIR1       =FEAT/CONTACT/CIRCLE/DEFAULT,CARTESIAN,IN,LEAST_SQR
            THEO/<14.3851,12.9007,0.06>,<0,0,1>,0.188
            ACTL/<14.3851,12.9007,0.06>,<0,0,1>,0.188
            TARG/<14.3851,12.9007,0.06>,<0,0,1>
            START ANG=0,END ANG=360
            ANGLE VEC=<1,0,0>
            DIRECTION=CCW
            SHOW FEATURE PARAMETERS=NO
            SHOW CONTACT PARAMETERS=YES
              NUMHITS=5,DEPTH=0.02,PITCH=0
              SAMPLE METHOD=SAMPLE_FEATURE
              SAMPLE FEATURE=NONE
              AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              FIND HOLE=DISABLED,ONERROR=NO,READ POS=NO
            SHOW HITS=NO
K1         =FEAT/CONTACT/CIRCLE/DEFAULT,CARTESIAN,IN,LEAST_SQR
            THEO/<15.2901,12.9007,0.06>,<0,0,1>,0.5
            ACTL/<15.2901,12.9007,0.06>,<0,0,1>,0.5
            TARG/<15.2901,12.9007,0.06>,<0,0,1>
            START ANG=0,END ANG=360
            ANGLE VEC=<1,0,0>
            DIRECTION=CCW
            SHOW FEATURE PARAMETERS=NO
            SHOW CONTACT PARAMETERS=YES
              NUMHITS=5,DEPTH=0.02,PITCH=0
              SAMPLE METHOD=SAMPLE_FEATURE
              SAMPLE FEATURE=NONE
              AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              FIND HOLE=DISABLED,ONERROR=NO,READ POS=NO
            SHOW HITS=NO
CIR2       =FEAT/CONTACT/CIRCLE/DEFAULT,CARTESIAN,IN,LEAST_SQR
            THEO/<16.1951,12.9007,0.06>,<0,0,1>,0.188
            ACTL/<16.1951,12.9007,0.06>,<0,0,1>,0.188
            TARG/<16.1951,12.9007,0.06>,<0,0,1>
            START ANG=0,END ANG=360
            ANGLE VEC=<1,0,0>
            DIRECTION=CCW
            SHOW FEATURE PARAMETERS=NO
            SHOW CONTACT PARAMETERS=YES
              NUMHITS=5,DEPTH=0.02,PITCH=0
              SAMPLE METHOD=SAMPLE_FEATURE
              SAMPLE FEATURE=NONE
              AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              FIND HOLE=DISABLED,ONERROR=NO,READ POS=NO
            SHOW HITS=NO
B12        =FEAT/CONTACT/CIRCLE/DEFAULT,CARTESIAN,IN,LEAST_SQR
            THEO/<14.7801,13.9407,0.06>,<0,0,1>,0.2
            ACTL/<14.7801,13.9407,0.06>,<0,0,1>,0.2
            TARG/<14.7801,13.9407,0.06>,<0,0,1>
            START ANG=0,END ANG=360
            ANGLE VEC=<1,0,0>
            DIRECTION=CCW
            SHOW FEATURE PARAMETERS=NO
            SHOW CONTACT PARAMETERS=YES
              NUMHITS=5,DEPTH=0.02,PITCH=0
              SAMPLE METHOD=SAMPLE_FEATURE
              SAMPLE FEATURE=NONE
              AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              FIND HOLE=DISABLED,ONERROR=NO,READ POS=NO
            SHOW HITS=NO
SLTS1      =FEAT/CONTACT/SQUARE SLOT/DEFAULT,CARTESIAN,IN
            THEO/<15.7301,13.9207,0.06>,<0,0,1>,<-1,0,0>,0.44,0.94
            ACTL/<15.7301,13.9207,0.06>,<0,0,1>,<-1,0,0>,0.44,0.94
            TARG/<15.7301,13.9207,0.06>,<0,0,1>,<-1,0,0>
            MEAS WIDTH=NO,RADIUS=0.0689
            SHOW FEATURE PARAMETERS=NO
            SHOW CONTACT PARAMETERS=YES
              DEPTH=0.02
              SAMPLE METHOD=SAMPLE_FEATURE
              SAMPLE FEATURE=NONE
              AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              FIND HOLE=DISABLED,ONERROR=NO,READ POS=NO
            SHOW HITS=NO
A17        =FEAT/CONTACT/CIRCLE/DEFAULT,CARTESIAN,IN,LEAST_SQR
            THEO/<17.5101,13.7207,0.06>,<0,0,1>,0.48
            ACTL/<17.5101,13.7207,0.06>,<0,0,1>,0.48
            TARG/<17.5101,13.7207,0.06>,<0,0,1>
            START ANG=27.9,END ANG=333.1
            ANGLE VEC=<1,0,0>
            DIRECTION=CCW
            SHOW FEATURE PARAMETERS=NO
            SHOW CONTACT PARAMETERS=YES
              NUMHITS=5,DEPTH=0.02,PITCH=0
              SAMPLE METHOD=SAMPLE_FEATURE
              SAMPLE FEATURE=NONE
              AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              FIND HOLE=DISABLED,ONERROR=NO,READ POS=NO
            SHOW HITS=NO
A17B       =FEAT/CONTACT/CIRCLE/DEFAULT,CARTESIAN,IN,LEAST_SQR
            THEO/<17.8801,13.7207,0.06>,<0,0,1>,0.128
            ACTL/<17.8801,13.7207,0.06>,<0,0,1>,0.128
            TARG/<17.8801,13.7207,0.06>,<0,0,1>
            START ANG=270,END ANG=450
            ANGLE VEC=<1,0,0>
            DIRECTION=CCW
            SHOW FEATURE PARAMETERS=NO
            SHOW CONTACT PARAMETERS=YES
              NUMHITS=5,DEPTH=0.02,PITCH=0
              SAMPLE METHOD=SAMPLE_FEATURE
              SAMPLE FEATURE=NONE
              AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              FIND HOLE=DISABLED,ONERROR=NO,READ POS=NO
            SHOW HITS=NO
A16        =FEAT/CONTACT/CIRCLE/DEFAULT,CARTESIAN,IN,LEAST_SQR
            THEO/<17.5101,12.4207,0.06>,<0,0,1>,0.48
            ACTL/<17.5101,12.4207,0.06>,<0,0,1>,0.48
            TARG/<17.5101,12.4207,0.06>,<0,0,1>
            START ANG=27.3,END ANG=332.9
            ANGLE VEC=<1,0,0>
            DIRECTION=CCW
            SHOW FEATURE PARAMETERS=NO
            SHOW CONTACT PARAMETERS=YES
              NUMHITS=5,DEPTH=0.02,PITCH=0
              SAMPLE METHOD=SAMPLE_FEATURE
              SAMPLE FEATURE=NONE
              AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              FIND HOLE=DISABLED,ONERROR=NO,READ POS=NO
            SHOW HITS=NO
A16B       =FEAT/CONTACT/CIRCLE/DEFAULT,CARTESIAN,IN,LEAST_SQR
            THEO/<17.8801,12.4207,0.06>,<0,0,1>,0.128
            ACTL/<17.8801,12.4207,0.06>,<0,0,1>,0.128
            TARG/<17.8801,12.4207,0.06>,<0,0,1>
            START ANG=270,END ANG=450
            ANGLE VEC=<1,0,0>
            DIRECTION=CCW
            SHOW FEATURE PARAMETERS=NO
            SHOW CONTACT PARAMETERS=YES
              NUMHITS=5,DEPTH=0.02,PITCH=0
              SAMPLE METHOD=SAMPLE_FEATURE
              SAMPLE FEATURE=NONE
              AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              FIND HOLE=DISABLED,ONERROR=NO,READ POS=NO
            SHOW HITS=NO
B11        =FEAT/CONTACT/CIRCLE/DEFAULT,CARTESIAN,IN,LEAST_SQR
            THEO/<18.3411,12.0582,0.06>,<0,0,1>,0.2
            ACTL/<18.3411,12.0582,0.06>,<0,0,1>,0.2
            TARG/<18.3411,12.0582,0.06>,<0,0,1>
            START ANG=0,END ANG=360
            ANGLE VEC=<1,0,0>
            DIRECTION=CCW
            SHOW FEATURE PARAMETERS=NO
            SHOW CONTACT PARAMETERS=YES
              NUMHITS=5,DEPTH=0.03,PITCH=0
              SAMPLE METHOD=SAMPLE_FEATURE
              SAMPLE FEATURE=NONE
              AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              FIND HOLE=DISABLED,ONERROR=NO,READ POS=NO
            SHOW HITS=NO
B10        =FEAT/CONTACT/CIRCLE/DEFAULT,CARTESIAN,IN,LEAST_SQR
            THEO/<18.3411,14.0832,0.06>,<0,0,1>,0.2
            ACTL/<18.3411,14.0832,0.06>,<0,0,1>,0.2
            TARG/<18.3411,14.0832,0.06>,<0,0,1>
            START ANG=0,END ANG=360
            ANGLE VEC=<1,0,0>
            DIRECTION=CCW
            SHOW FEATURE PARAMETERS=NO
            SHOW CONTACT PARAMETERS=YES
              NUMHITS=5,DEPTH=0.03,PITCH=0
              SAMPLE METHOD=SAMPLE_FEATURE
              SAMPLE FEATURE=NONE
              AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              FIND HOLE=DISABLED,ONERROR=NO,READ POS=NO
            SHOW HITS=NO
J1         =FEAT/CONTACT/SQUARE SLOT/DEFAULT,CARTESIAN,IN
            THEO/<19.0601,13.0707,0.06>,<0,0,1>,<1,0,0>,0.28,1.15
            ACTL/<19.0601,13.0707,0.06>,<0,0,1>,<1,0,0>,0.28,1.15
            TARG/<19.0601,13.0707,0.06>,<0,0,1>,<1,0,0>
            MEAS WIDTH=NO,RADIUS=0.0689
            SHOW FEATURE PARAMETERS=NO
            SHOW CONTACT PARAMETERS=YES
              DEPTH=0.03
              SAMPLE METHOD=SAMPLE_FEATURE
              SAMPLE FEATURE=NONE
              AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              FIND HOLE=DISABLED,ONERROR=NO,READ POS=NO
            SHOW HITS=NO
H1         =FEAT/CONTACT/CIRCLE/DEFAULT,CARTESIAN,IN,LEAST_SQR
            THEO/<19.6451,12.3207,0.06>,<0,0,1>,0.515
            ACTL/<19.6451,12.3207,0.06>,<0,0,1>,0.515
            TARG/<19.6451,12.3207,0.06>,<0,0,1>
            START ANG=289.3,END ANG=611.8
            ANGLE VEC=<1,0,0>
            DIRECTION=CCW
            SHOW FEATURE PARAMETERS=NO
            SHOW CONTACT PARAMETERS=YES
              NUMHITS=5,DEPTH=0.03,PITCH=0
              SAMPLE METHOD=SAMPLE_FEATURE
              SAMPLE FEATURE=NONE
              AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              FIND HOLE=DISABLED,ONERROR=NO,READ POS=NO
            SHOW HITS=NO
            MOVE/POINT,NORMAL,<19.6451,12,2.5>
            TIP/T1A10B0, SHANKIJK=0, 0.1736, 0.9848, ANGLE=0
            MOVE/POINT,NORMAL,<19.6451,12,2.5>
H1B        =FEAT/CONTACT/CIRCLE/DEFAULT,CARTESIAN,IN,LEAST_SQR
            THEO/<19.6451,11.9147,0.06>,<0,0,1>,0.125
            ACTL/<19.6451,11.9147,0.06>,<0,0,1>,0.125
            TARG/<19.6451,11.9147,0.06>,<0,0,1>
            START ANG=180.0026,END ANG=360
            ANGLE VEC=<1,0,0>
            DIRECTION=CCW
            SHOW FEATURE PARAMETERS=NO
            SHOW CONTACT PARAMETERS=YES
              NUMHITS=5,DEPTH=0.03,PITCH=0
              SAMPLE METHOD=SAMPLE_FEATURE
              SAMPLE FEATURE=NONE
              AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              FIND HOLE=DISABLED,ONERROR=NO,READ POS=NO
            SHOW HITS=NO
            MOVE/POINT,NORMAL,<19.6451,12,2.5>
            TIP/T1A-10B0, SHANKIJK=0, -0.1736, 0.9848, ANGLE=0
            MOVE/POINT,NORMAL,<19.6451,14,2.5>
H2B        =FEAT/CONTACT/CIRCLE/DEFAULT,CARTESIAN,IN,LEAST_SQR
            THEO/<19.6451,14.2267,0.06>,<0,0,1>,0.125
            ACTL/<19.6451,14.2267,0.06>,<0,0,1>,0.125
            TARG/<19.6451,14.2267,0.06>,<0,0,1>
            START ANG=0.0802,END ANG=179.9993
            ANGLE VEC=<1,0,0>
            DIRECTION=CCW
            SHOW FEATURE PARAMETERS=NO
            SHOW CONTACT PARAMETERS=YES
              NUMHITS=5,DEPTH=0.03,PITCH=0
              SAMPLE METHOD=SAMPLE_FEATURE
              SAMPLE FEATURE=NONE
              AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              FIND HOLE=DISABLED,ONERROR=NO,READ POS=NO
            SHOW HITS=NO
            MOVE/POINT,NORMAL,<19.6451,14,2.5>
            TIP/T1A0B0, SHANKIJK=0, 0, 1, ANGLE=0
H2         =FEAT/CONTACT/CIRCLE/DEFAULT,CARTESIAN,IN,LEAST_SQR
            THEO/<19.6451,13.8207,0.06>,<0,0,1>,0.473
            ACTL/<19.6451,13.8207,0.06>,<0,0,1>,0.473
            TARG/<19.6451,13.8207,0.06>,<0,0,1>
            START ANG=109.3,END ANG=430.9
            ANGLE VEC=<1,0,0>
            DIRECTION=CCW
            SHOW FEATURE PARAMETERS=NO
            SHOW CONTACT PARAMETERS=YES
              NUMHITS=5,DEPTH=0.03,PITCH=0
              SAMPLE METHOD=SAMPLE_FEATURE
              SAMPLE FEATURE=NONE
              AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              FIND HOLE=DISABLED,ONERROR=NO,READ POS=NO
            SHOW HITS=NO
G1         =FEAT/CONTACT/SQUARE SLOT/DEFAULT,CARTESIAN,IN
            THEO/<20.4751,13.6707,0.06>,<0,0,1>,<0,1,0>,0.44,0.94
            ACTL/<20.4751,13.6707,0.06>,<0,0,1>,<0,1,0>,0.44,0.94
            TARG/<20.4751,13.6707,0.06>,<0,0,1>,<0,1,0>
            MEAS WIDTH=NO,RADIUS=0.0689
            SHOW FEATURE PARAMETERS=NO
            SHOW CONTACT PARAMETERS=YES
              DEPTH=0.03
              SAMPLE METHOD=SAMPLE_FEATURE
              SAMPLE FEATURE=NONE
              AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              FIND HOLE=DISABLED,ONERROR=NO,READ POS=NO
            SHOW HITS=NO
G2         =FEAT/CONTACT/SQUARE SLOT/DEFAULT,CARTESIAN,IN
            THEO/<20.4751,12.4707,0.06>,<0,0,1>,<0,1,0>,0.44,0.94
            ACTL/<20.4751,12.4707,0.06>,<0,0,1>,<0,1,0>,0.44,0.94
            TARG/<20.4751,12.4707,0.06>,<0,0,1>,<0,1,0>
            MEAS WIDTH=NO,RADIUS=0.0689
            SHOW FEATURE PARAMETERS=NO
            SHOW CONTACT PARAMETERS=YES
              DEPTH=0.03
              SAMPLE METHOD=SAMPLE_FEATURE
              SAMPLE FEATURE=NONE
              AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              FIND HOLE=DISABLED,ONERROR=NO,READ POS=NO
            SHOW HITS=NO
G5         =FEAT/CONTACT/SQUARE SLOT/DEFAULT,CARTESIAN,IN
            THEO/<21.525,13.6207,0.06>,<0,0,1>,<0,-1,0>,0.44,0.94
            ACTL/<21.525,13.6207,0.06>,<0,0,1>,<0,-1,0>,0.44,0.94
            TARG/<21.525,13.6207,0.06>,<0,0,1>,<0,-1,0>
            MEAS WIDTH=NO,RADIUS=0.0689
            SHOW FEATURE PARAMETERS=NO
            SHOW CONTACT PARAMETERS=YES
              DEPTH=0.03
              SAMPLE METHOD=SAMPLE_FEATURE
              SAMPLE FEATURE=NONE
              AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              FIND HOLE=DISABLED,ONERROR=NO,READ POS=NO
            SHOW HITS=NO
A15        =FEAT/CONTACT/CIRCLE/DEFAULT,CARTESIAN,IN,LEAST_SQR
            THEO/<21.525,12.4707,0.06>,<0,0,1>,0.515
            ACTL/<21.525,12.4707,0.06>,<0,0,1>,0.515
            TARG/<21.525,12.4707,0.06>,<0,0,1>
            START ANG=20.7,END ANG=338.7
            ANGLE VEC=<1,0,0>
            DIRECTION=CCW
            SHOW FEATURE PARAMETERS=NO
            SHOW CONTACT PARAMETERS=YES
              NUMHITS=5,DEPTH=0.03,PITCH=0
              SAMPLE METHOD=SAMPLE_FEATURE
              SAMPLE FEATURE=NONE
              AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              FIND HOLE=DISABLED,ONERROR=NO,READ POS=NO
            SHOW HITS=NO
A15B       =FEAT/CONTACT/CIRCLE/DEFAULT,CARTESIAN,IN,LEAST_SQR
            THEO/<21.931,12.4707,0.06>,<0,0,1>,0.125
            ACTL/<21.931,12.4707,0.06>,<0,0,1>,0.125
            TARG/<21.931,12.4707,0.06>,<0,0,1>
            START ANG=270.0072,END ANG=449.9909
            ANGLE VEC=<1,0,0>
            DIRECTION=CCW
            SHOW FEATURE PARAMETERS=NO
            SHOW CONTACT PARAMETERS=YES
              NUMHITS=5,DEPTH=0.03,PITCH=0
              SAMPLE METHOD=SAMPLE_FEATURE
              SAMPLE FEATURE=NONE
              AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              FIND HOLE=DISABLED,ONERROR=NO,READ POS=NO
            SHOW HITS=NO
E2         =FEAT/CONTACT/CIRCLE/DEFAULT,CARTESIAN,IN,LEAST_SQR
            THEO/<22.8012,13.9728,0.06>,<0,0,1>,0.5
            ACTL/<22.8012,13.9728,0.06>,<0,0,1>,0.5
            TARG/<22.8012,13.9728,0.06>,<0,0,1>
            START ANG=0,END ANG=360
            ANGLE VEC=<1,0,0>
            DIRECTION=CCW
            SHOW FEATURE PARAMETERS=NO
            SHOW CONTACT PARAMETERS=YES
              NUMHITS=5,DEPTH=0.02,PITCH=0
              SAMPLE METHOD=SAMPLE_FEATURE
              SAMPLE FEATURE=NONE
              AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              FIND HOLE=DISABLED,ONERROR=NO,READ POS=NO
            SHOW HITS=NO
A14        =FEAT/CONTACT/CIRCLE/DEFAULT,CARTESIAN,IN,LEAST_SQR
            THEO/<23.4201,13.0707,0.06>,<0,0,1>,0.48
            ACTL/<23.4201,13.0707,0.06>,<0,0,1>,0.48
            TARG/<23.4201,13.0707,0.06>,<0,0,1>
            START ANG=29.2,END ANG=330.3
            ANGLE VEC=<1,0,0>
            DIRECTION=CCW
            SHOW FEATURE PARAMETERS=NO
            SHOW CONTACT PARAMETERS=YES
              NUMHITS=5,DEPTH=0.025,PITCH=0
              SAMPLE METHOD=SAMPLE_FEATURE
              SAMPLE FEATURE=NONE
              AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              FIND HOLE=DISABLED,ONERROR=NO,READ POS=NO
            SHOW HITS=NO
A14B       =FEAT/CONTACT/CIRCLE/DEFAULT,CARTESIAN,IN,LEAST_SQR
            THEO/<23.7901,13.0707,0.06>,<0,0,1>,0.128
            ACTL/<23.7901,13.0707,0.06>,<0,0,1>,0.128
            TARG/<23.7901,13.0707,0.06>,<0,0,1>
            START ANG=270,END ANG=450
            ANGLE VEC=<1,0,0>
            DIRECTION=CCW
            SHOW FEATURE PARAMETERS=NO
            SHOW CONTACT PARAMETERS=YES
              NUMHITS=5,DEPTH=0.02,PITCH=0
              SAMPLE METHOD=SAMPLE_FEATURE
              SAMPLE FEATURE=NONE
              AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              FIND HOLE=DISABLED,ONERROR=NO,READ POS=NO
            SHOW HITS=NO
B9         =FEAT/CONTACT/CIRCLE/DEFAULT,CARTESIAN,IN,LEAST_SQR
            THEO/<24.21,12.0582,0.06>,<0,0,1>,0.2
            ACTL/<24.21,12.0582,0.06>,<0,0,1>,0.2
            TARG/<24.21,12.0582,0.06>,<0,0,1>
            START ANG=0,END ANG=360
            ANGLE VEC=<1,0,0>
            DIRECTION=CCW
            SHOW FEATURE PARAMETERS=NO
            SHOW CONTACT PARAMETERS=YES
              NUMHITS=5,DEPTH=0.02,PITCH=0
              SAMPLE METHOD=SAMPLE_FEATURE
              SAMPLE FEATURE=NONE
              AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              FIND HOLE=DISABLED,ONERROR=NO,READ POS=NO
            SHOW HITS=NO
B8         =FEAT/CONTACT/CIRCLE/DEFAULT,CARTESIAN,IN,LEAST_SQR
            THEO/<24.21,14.0832,0.06>,<0,0,1>,0.2
            ACTL/<24.21,14.0832,0.06>,<0,0,1>,0.2
            TARG/<24.21,14.0832,0.06>,<0,0,1>
            START ANG=0,END ANG=360
            ANGLE VEC=<1,0,0>
            DIRECTION=CCW
            SHOW FEATURE PARAMETERS=NO
            SHOW CONTACT PARAMETERS=YES
              NUMHITS=5,DEPTH=0.02,PITCH=0
              SAMPLE METHOD=SAMPLE_FEATURE
              SAMPLE FEATURE=NONE
              AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              FIND HOLE=DISABLED,ONERROR=NO,READ POS=NO
            SHOW HITS=NO
            MOVE/POINT,NORMAL,<24.21,14.0832,2.2>
            MOVE/POINT,NORMAL,<25.2358,25.2551,2.2>
CIR4       =FEAT/CONTACT/CIRCLE/DEFAULT,CARTESIAN,IN,LEAST_SQR
            THEO/<25.2358,25.2551,0.113>,<0,0,1>,0.4755
            ACTL/<25.2358,25.2551,0.113>,<0,0,1>,0.4755
            TARG/<25.2358,25.2551,0.113>,<0,0,1>
            START ANG=0,END ANG=360
            ANGLE VEC=<1,0,0>
            DIRECTION=CCW
            SHOW FEATURE PARAMETERS=NO
            SHOW CONTACT PARAMETERS=YES
              NUMHITS=5,DEPTH=0.02,PITCH=0
              SAMPLE METHOD=SAMPLE_FEATURE
              SAMPLE FEATURE=NONE
              AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              FIND HOLE=DISABLED,ONERROR=NO,READ POS=NO
            SHOW HITS=NO
B7         =FEAT/CONTACT/CIRCLE/DEFAULT,CARTESIAN,IN,LEAST_SQR
            THEO/<24.8911,24.4407,0.113>,<0,0,1>,0.2
            ACTL/<24.8911,24.4407,0.113>,<0,0,1>,0.2
            TARG/<24.8911,24.4407,0.113>,<0,0,1>
            START ANG=0,END ANG=360
            ANGLE VEC=<1,0,0>
            DIRECTION=CCW
            SHOW FEATURE PARAMETERS=NO
            SHOW CONTACT PARAMETERS=YES
              NUMHITS=5,DEPTH=0.03,PITCH=0
              SAMPLE METHOD=SAMPLE_FEATURE
              SAMPLE FEATURE=NONE
              AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              FIND HOLE=DISABLED,ONERROR=NO,READ POS=NO
            SHOW HITS=NO
A13        =FEAT/CONTACT/CIRCLE/DEFAULT,CARTESIAN,IN,LEAST_SQR
            THEO/<25.6611,21.78,0.113>,<0,0,1>,0.48
            ACTL/<25.6611,21.78,0.113>,<0,0,1>,0.48
            TARG/<25.6611,21.78,0.113>,<0,0,1>
            START ANG=27.3,END ANG=333
            ANGLE VEC=<1,0,0>
            DIRECTION=CCW
            SHOW FEATURE PARAMETERS=NO
            SHOW CONTACT PARAMETERS=YES
              NUMHITS=5,DEPTH=0.03,PITCH=0
              SAMPLE METHOD=SAMPLE_FEATURE
              SAMPLE FEATURE=NONE
              AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              FIND HOLE=DISABLED,ONERROR=NO,READ POS=NO
            SHOW HITS=NO
A13B       =FEAT/CONTACT/CIRCLE/DEFAULT,CARTESIAN,IN,LEAST_SQR
            THEO/<26.0311,21.78,0.113>,<0,0,1>,0.1327
            ACTL/<26.0311,21.78,0.113>,<0,0,1>,0.1327
            TARG/<26.0311,21.78,0.113>,<0,0,1>
            START ANG=270,END ANG=450
            ANGLE VEC=<1,0,0>
            DIRECTION=CCW
            SHOW FEATURE PARAMETERS=NO
            SHOW CONTACT PARAMETERS=YES
              NUMHITS=5,DEPTH=0.03,PITCH=0
              SAMPLE METHOD=SAMPLE_FEATURE
              SAMPLE FEATURE=NONE
              AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              FIND HOLE=DISABLED,ONERROR=NO,READ POS=NO
            SHOW HITS=NO
A12        =FEAT/CONTACT/CIRCLE/DEFAULT,CARTESIAN,IN,LEAST_SQR
            THEO/<25.6611,20.75,0.113>,<0,0,1>,0.48
            ACTL/<25.6611,20.75,0.113>,<0,0,1>,0.48
            TARG/<25.6611,20.75,0.113>,<0,0,1>
            START ANG=28.3,END ANG=332.3
            ANGLE VEC=<1,0,0>
            DIRECTION=CCW
            SHOW FEATURE PARAMETERS=NO
            SHOW CONTACT PARAMETERS=YES
              NUMHITS=5,DEPTH=0.03,PITCH=0
              SAMPLE METHOD=SAMPLE_FEATURE
              SAMPLE FEATURE=NONE
              AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              FIND HOLE=DISABLED,ONERROR=NO,READ POS=NO
            SHOW HITS=NO
A12B       =FEAT/CONTACT/CIRCLE/DEFAULT,CARTESIAN,IN,LEAST_SQR
            THEO/<26.0311,20.75,0.113>,<0,0,1>,0.128
            ACTL/<26.0311,20.75,0.113>,<0,0,1>,0.128
            TARG/<26.0311,20.75,0.113>,<0,0,1>
            START ANG=270,END ANG=450
            ANGLE VEC=<1,0,0>
            DIRECTION=CCW
            SHOW FEATURE PARAMETERS=NO
            SHOW CONTACT PARAMETERS=YES
              NUMHITS=5,DEPTH=0.03,PITCH=0
              SAMPLE METHOD=SAMPLE_FEATURE
              SAMPLE FEATURE=NONE
              AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              FIND HOLE=DISABLED,ONERROR=NO,READ POS=NO
            SHOW HITS=NO
B6         =FEAT/CONTACT/CIRCLE/DEFAULT,CARTESIAN,IN,LEAST_SQR
            THEO/<26.8011,20.1407,0.113>,<0,0,1>,0.2
            ACTL/<26.8011,20.1407,0.113>,<0,0,1>,0.2
            TARG/<26.8011,20.1407,0.113>,<0,0,1>
            START ANG=0,END ANG=360
            ANGLE VEC=<1,0,0>
            DIRECTION=CCW
            SHOW FEATURE PARAMETERS=NO
            SHOW CONTACT PARAMETERS=YES
              NUMHITS=5,DEPTH=0.03,PITCH=0
              SAMPLE METHOD=SAMPLE_FEATURE
              SAMPLE FEATURE=NONE
              AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              FIND HOLE=DISABLED,ONERROR=NO,READ POS=NO
            SHOW HITS=NO
E1         =FEAT/CONTACT/CIRCLE/DEFAULT,CARTESIAN,IN,LEAST_SQR
            THEO/<27.1911,19.1907,0.113>,<0,0,1>,0.5
            ACTL/<27.1911,19.1907,0.113>,<0,0,1>,0.5
            TARG/<27.1911,19.1907,0.113>,<0,0,1>
            START ANG=0,END ANG=360
            ANGLE VEC=<1,0,0>
            DIRECTION=CCW
            SHOW FEATURE PARAMETERS=NO
            SHOW CONTACT PARAMETERS=YES
              NUMHITS=5,DEPTH=0.03,PITCH=0
              SAMPLE METHOD=SAMPLE_FEATURE
              SAMPLE FEATURE=NONE
              AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              FIND HOLE=DISABLED,ONERROR=NO,READ POS=NO
            SHOW HITS=NO
A10        =FEAT/CONTACT/CIRCLE/DEFAULT,CARTESIAN,IN,LEAST_SQR
            THEO/<25.6611,18.9607,0.113>,<0,0,1>,0.48
            ACTL/<25.6611,18.9607,0.113>,<0,0,1>,0.48
            TARG/<25.6611,18.9607,0.113>,<0,0,1>
            START ANG=24.4145,END ANG=328.6
            ANGLE VEC=<1,0,0>
            DIRECTION=CCW
            SHOW FEATURE PARAMETERS=NO
            SHOW CONTACT PARAMETERS=YES
              NUMHITS=5,DEPTH=0.03,PITCH=0
              SAMPLE METHOD=SAMPLE_FEATURE
              SAMPLE FEATURE=NONE
              AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              FIND HOLE=DISABLED,ONERROR=NO,READ POS=NO
            SHOW HITS=NO
A10B       =FEAT/CONTACT/CIRCLE/DEFAULT,CARTESIAN,IN,LEAST_SQR
            THEO/<26.0311,18.9607,0.113>,<0,0,1>,0.128
            ACTL/<26.0311,18.9607,0.113>,<0,0,1>,0.128
            TARG/<26.0311,18.9607,0.113>,<0,0,1>
            START ANG=270,END ANG=450
            ANGLE VEC=<1,0,0>
            DIRECTION=CCW
            SHOW FEATURE PARAMETERS=NO
            SHOW CONTACT PARAMETERS=YES
              NUMHITS=5,DEPTH=0.03,PITCH=0
              SAMPLE METHOD=SAMPLE_FEATURE
              SAMPLE FEATURE=NONE
              AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              FIND HOLE=DISABLED,ONERROR=NO,READ POS=NO
            SHOW HITS=NO
A9         =FEAT/CONTACT/CIRCLE/DEFAULT,CARTESIAN,IN,LEAST_SQR
            THEO/<25.6611,17.9507,0.113>,<0,0,1>,0.48
            ACTL/<25.6611,17.9507,0.113>,<0,0,1>,0.48
            TARG/<25.6611,17.9507,0.113>,<0,0,1>
            START ANG=27.3,END ANG=331.1
            ANGLE VEC=<1,0,0>
            DIRECTION=CCW
            SHOW FEATURE PARAMETERS=NO
            SHOW CONTACT PARAMETERS=YES
              NUMHITS=5,DEPTH=0.03,PITCH=0
              SAMPLE METHOD=SAMPLE_FEATURE
              SAMPLE FEATURE=NONE
              AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              FIND HOLE=DISABLED,ONERROR=NO,READ POS=NO
            SHOW HITS=NO
A9B        =FEAT/CONTACT/CIRCLE/DEFAULT,CARTESIAN,IN,LEAST_SQR
            THEO/<26.0311,17.9507,0.113>,<0,0,1>,0.128
            ACTL/<26.0311,17.9507,0.113>,<0,0,1>,0.128
            TARG/<26.0311,17.9507,0.113>,<0,0,1>
            START ANG=270,END ANG=450
            ANGLE VEC=<1,0,0>
            DIRECTION=CCW
            SHOW FEATURE PARAMETERS=NO
            SHOW CONTACT PARAMETERS=YES
              NUMHITS=5,DEPTH=0.03,PITCH=0
              SAMPLE METHOD=SAMPLE_FEATURE
              SAMPLE FEATURE=NONE
              AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              FIND HOLE=DISABLED,ONERROR=NO,READ POS=NO
            SHOW HITS=NO
A8         =FEAT/CONTACT/CIRCLE/DEFAULT,CARTESIAN,IN,LEAST_SQR
            THEO/<25.6611,16.9507,0.113>,<0,0,1>,0.48
            ACTL/<25.6611,16.9507,0.113>,<0,0,1>,0.48
            TARG/<25.6611,16.9507,0.113>,<0,0,1>
            START ANG=24.4145,END ANG=335.5857
            ANGLE VEC=<1,0,0>
            DIRECTION=CCW
            SHOW FEATURE PARAMETERS=NO
            SHOW CONTACT PARAMETERS=YES
              NUMHITS=5,DEPTH=0.03,PITCH=0
              SAMPLE METHOD=SAMPLE_FEATURE
              SAMPLE FEATURE=NONE
              AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              FIND HOLE=DISABLED,ONERROR=NO,READ POS=NO
            SHOW HITS=NO
A8B        =FEAT/CONTACT/CIRCLE/DEFAULT,CARTESIAN,IN,LEAST_SQR
            THEO/<26.0311,16.9507,0.113>,<0,0,1>,0.128
            ACTL/<26.0311,16.9507,0.113>,<0,0,1>,0.128
            TARG/<26.0311,16.9507,0.113>,<0,0,1>
            START ANG=270,END ANG=450
            ANGLE VEC=<1,0,0>
            DIRECTION=CCW
            SHOW FEATURE PARAMETERS=NO
            SHOW CONTACT PARAMETERS=YES
              NUMHITS=5,DEPTH=0.03,PITCH=0
              SAMPLE METHOD=SAMPLE_FEATURE
              SAMPLE FEATURE=NONE
              AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              FIND HOLE=DISABLED,ONERROR=NO,READ POS=NO
            SHOW HITS=NO
CIR7       =FEAT/CONTACT/CIRCLE/DEFAULT,CARTESIAN,IN,LEAST_SQR
            THEO/<27.1161,16.1107,0.113>,<0,0,1>,0.188
            ACTL/<27.1161,16.1107,0.113>,<0,0,1>,0.188
            TARG/<27.1161,16.1107,0.113>,<0,0,1>
            START ANG=0,END ANG=360
            ANGLE VEC=<1,0,0>
            DIRECTION=CCW
            SHOW FEATURE PARAMETERS=NO
            SHOW CONTACT PARAMETERS=YES
              NUMHITS=5,DEPTH=0.03,PITCH=0
              SAMPLE METHOD=SAMPLE_FEATURE
              SAMPLE FEATURE=NONE
              AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              FIND HOLE=DISABLED,ONERROR=NO,READ POS=NO
            SHOW HITS=NO
D1         =FEAT/CONTACT/SQUARE SLOT/DEFAULT,CARTESIAN,IN
            THEO/<26.2111,16.1107,0.113>,<0,0,1>,<-1,0,0>,0.46,0.92
            ACTL/<26.2111,16.1107,0.113>,<0,0,1>,<-1,0,0>,0.46,0.92
            TARG/<26.2111,16.1107,0.113>,<0,0,1>,<-1,0,0>
            MEAS WIDTH=NO,RADIUS=0.0689
            SHOW FEATURE PARAMETERS=NO
            SHOW CONTACT PARAMETERS=YES
              DEPTH=0.03
              SAMPLE METHOD=SAMPLE_FEATURE
              SAMPLE FEATURE=NONE
              AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              FIND HOLE=DISABLED,ONERROR=NO,READ POS=NO
            SHOW HITS=NO
CIR8       =FEAT/CONTACT/CIRCLE/DEFAULT,CARTESIAN,IN,LEAST_SQR
            THEO/<25.3061,16.1107,0.113>,<0,0,1>,0.188
            ACTL/<25.3061,16.1107,0.113>,<0,0,1>,0.188
            TARG/<25.3061,16.1107,0.113>,<0,0,1>
            START ANG=0,END ANG=360
            ANGLE VEC=<1,0,0>
            DIRECTION=CCW
            SHOW FEATURE PARAMETERS=NO
            SHOW CONTACT PARAMETERS=YES
              NUMHITS=5,DEPTH=0.03,PITCH=0
              SAMPLE METHOD=SAMPLE_FEATURE
              SAMPLE FEATURE=NONE
              AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              FIND HOLE=DISABLED,ONERROR=NO,READ POS=NO
            SHOW HITS=NO
B5         =FEAT/CONTACT/CIRCLE/DEFAULT,CARTESIAN,IN,LEAST_SQR
            THEO/<24.8911,16.1707,0.113>,<0,0,1>,0.2
            ACTL/<24.8911,16.1707,0.113>,<0,0,1>,0.2
            TARG/<24.8911,16.1707,0.113>,<0,0,1>
            START ANG=0,END ANG=360
            ANGLE VEC=<1,0,0>
            DIRECTION=CCW
            SHOW FEATURE PARAMETERS=NO
            SHOW CONTACT PARAMETERS=YES
              NUMHITS=5,DEPTH=0.03,PITCH=0
              SAMPLE METHOD=SAMPLE_FEATURE
              SAMPLE FEATURE=NONE
              AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              FIND HOLE=DISABLED,ONERROR=NO,READ POS=NO
            SHOW HITS=NO
C1         =FEAT/CONTACT/CIRCLE/DEFAULT,CARTESIAN,IN,LEAST_SQR
            THEO/<25.87,14.0707,0.113>,<0,0,1>,0.5
            ACTL/<25.87,14.0707,0.113>,<0,0,1>,0.5
            TARG/<25.87,14.0707,0.113>,<0,0,1>
            START ANG=58.2,END ANG=361.3
            ANGLE VEC=<1,0,0>
            DIRECTION=CCW
            SHOW FEATURE PARAMETERS=NO
            SHOW CONTACT PARAMETERS=YES
              NUMHITS=5,DEPTH=0.03,PITCH=0
              SAMPLE METHOD=SAMPLE_FEATURE
              SAMPLE FEATURE=NONE
              AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              FIND HOLE=DISABLED,ONERROR=NO,READ POS=NO
            SHOW HITS=NO
C1B        =FEAT/CONTACT/CIRCLE/DEFAULT,CARTESIAN,IN,LEAST_SQR
            THEO/<26.3203,14.3307,0.113>,<0,0,1>,0.16
            ACTL/<26.3203,14.3307,0.113>,<0,0,1>,0.16
            TARG/<26.3203,14.3307,0.113>,<0,0,1>
            START ANG=300.0004,END ANG=480
            ANGLE VEC=<1,0,0>
            DIRECTION=CCW
            SHOW FEATURE PARAMETERS=NO
            SHOW CONTACT PARAMETERS=YES
              NUMHITS=5,DEPTH=0.03,PITCH=0
              SAMPLE METHOD=SAMPLE_FEATURE
              SAMPLE FEATURE=NONE
              AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              FIND HOLE=DISABLED,ONERROR=NO,READ POS=NO
            SHOW HITS=NO
B4         =FEAT/CONTACT/CIRCLE/DEFAULT,CARTESIAN,IN,LEAST_SQR
            THEO/<27.5701,13.4619,0.113>,<0,0,1>,0.2
            ACTL/<27.5701,13.4619,0.113>,<0,0,1>,0.2
            TARG/<27.5701,13.4619,0.113>,<0,0,1>
            START ANG=0,END ANG=360
            ANGLE VEC=<1,0,0>
            DIRECTION=CCW
            SHOW FEATURE PARAMETERS=NO
            SHOW CONTACT PARAMETERS=YES
              NUMHITS=5,DEPTH=0.03,PITCH=0
              SAMPLE METHOD=SAMPLE_FEATURE
              SAMPLE FEATURE=NONE
              AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              FIND HOLE=DISABLED,ONERROR=NO,READ POS=NO
            SHOW HITS=NO
CIR10      =FEAT/CONTACT/CIRCLE/DEFAULT,CARTESIAN,IN,LEAST_SQR
            THEO/<26.653,13.1214,0.113>,<0,0,1>,0.0938
            ACTL/<26.653,13.1214,0.113>,<0,0,1>,0.0938
            TARG/<26.653,13.1214,0.113>,<0,0,1>
            START ANG=0,END ANG=360
            ANGLE VEC=<1,0,0>
            DIRECTION=CCW
            SHOW FEATURE PARAMETERS=NO
            SHOW CONTACT PARAMETERS=YES
              NUMHITS=5,DEPTH=0.03,PITCH=0
              SAMPLE METHOD=SAMPLE_FEATURE
              SAMPLE FEATURE=NONE
              AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              FIND HOLE=DISABLED,ONERROR=NO,READ POS=NO
            SHOW HITS=NO
A7B        =FEAT/CONTACT/CIRCLE/DEFAULT,CARTESIAN,IN,LEAST_SQR
            THEO/<25.6611,12.2907,0.113>,<0,0,1>,0.128
            ACTL/<25.6611,12.2907,0.113>,<0,0,1>,0.128
            TARG/<25.6611,12.2907,0.113>,<0,0,1>
            START ANG=359.9984,END ANG=539.9999
            ANGLE VEC=<1,0,0>
            DIRECTION=CCW
            SHOW FEATURE PARAMETERS=NO
            SHOW CONTACT PARAMETERS=YES
              NUMHITS=5,DEPTH=0.03,PITCH=0
              SAMPLE METHOD=SAMPLE_FEATURE
              SAMPLE FEATURE=NONE
              AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              FIND HOLE=DISABLED,ONERROR=NO,READ POS=NO
            SHOW HITS=NO
A7         =FEAT/CONTACT/CIRCLE/DEFAULT,CARTESIAN,IN,LEAST_SQR
            THEO/<25.6611,11.9207,0.113>,<0,0,1>,0.48
            ACTL/<25.6611,11.9207,0.113>,<0,0,1>,0.48
            TARG/<25.6611,11.9207,0.113>,<0,0,1>
            START ANG=117.2,END ANG=423.9
            ANGLE VEC=<1,0,0>
            DIRECTION=CCW
            SHOW FEATURE PARAMETERS=NO
            SHOW CONTACT PARAMETERS=YES
              NUMHITS=5,DEPTH=0.03,PITCH=0
              SAMPLE METHOD=SAMPLE_FEATURE
              SAMPLE FEATURE=NONE
              AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              FIND HOLE=DISABLED,ONERROR=NO,READ POS=NO
            SHOW HITS=NO
C2B        =FEAT/CONTACT/CIRCLE/DEFAULT,CARTESIAN,IN,LEAST_SQR
            THEO/<26.3203,9.9007,0.113>,<0,0,1>,0.16
            ACTL/<26.3203,9.9007,0.113>,<0,0,1>,0.16
            TARG/<26.3203,9.9007,0.113>,<0,0,1>
            START ANG=300.0004,END ANG=480
            ANGLE VEC=<1,0,0>
            DIRECTION=CCW
            SHOW FEATURE PARAMETERS=NO
            SHOW CONTACT PARAMETERS=YES
              NUMHITS=5,DEPTH=0.03,PITCH=0
              SAMPLE METHOD=SAMPLE_FEATURE
              SAMPLE FEATURE=NONE
              AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              FIND HOLE=DISABLED,ONERROR=NO,READ POS=NO
            SHOW HITS=NO
C2         =FEAT/CONTACT/CIRCLE/DEFAULT,CARTESIAN,IN,LEAST_SQR
            THEO/<25.87,9.6407,0.113>,<0,0,1>,0.5
            ACTL/<25.87,9.6407,0.113>,<0,0,1>,0.5
            TARG/<25.87,9.6407,0.113>,<0,0,1>
            START ANG=59.8,END ANG=359.3
            ANGLE VEC=<1,0,0>
            DIRECTION=CCW
            SHOW FEATURE PARAMETERS=NO
            SHOW CONTACT PARAMETERS=YES
              NUMHITS=5,DEPTH=0.03,PITCH=0
              SAMPLE METHOD=SAMPLE_FEATURE
              SAMPLE FEATURE=NONE
              AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              FIND HOLE=DISABLED,ONERROR=NO,READ POS=NO
            SHOW HITS=NO
B3         =FEAT/CONTACT/CIRCLE/DEFAULT,CARTESIAN,IN,LEAST_SQR
            THEO/<24.8931,9.1147,0.113>,<0,0,1>,0.2
            ACTL/<24.8931,9.1147,0.113>,<0,0,1>,0.2
            TARG/<24.8931,9.1147,0.113>,<0,0,1>
            START ANG=0,END ANG=360
            ANGLE VEC=<1,0,0>
            DIRECTION=CCW
            SHOW FEATURE PARAMETERS=NO
            SHOW CONTACT PARAMETERS=YES
              NUMHITS=5,DEPTH=0.03,PITCH=0
              SAMPLE METHOD=SAMPLE_FEATURE
              SAMPLE FEATURE=NONE
              AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              FIND HOLE=DISABLED,ONERROR=NO,READ POS=NO
            SHOW HITS=NO
A6         =FEAT/CONTACT/CIRCLE/DEFAULT,CARTESIAN,IN,LEAST_SQR
            THEO/<25.6611,8.0207,0.113>,<0,0,1>,0.48
            ACTL/<25.6611,8.0207,0.113>,<0,0,1>,0.48
            TARG/<25.6611,8.0207,0.113>,<0,0,1>
            START ANG=24.4145,END ANG=335.5857
            ANGLE VEC=<1,0,0>
            DIRECTION=CCW
            SHOW FEATURE PARAMETERS=NO
            SHOW CONTACT PARAMETERS=YES
              NUMHITS=5,DEPTH=0.03,PITCH=0
              SAMPLE METHOD=SAMPLE_FEATURE
              SAMPLE FEATURE=NONE
              AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              FIND HOLE=DISABLED,ONERROR=NO,READ POS=NO
            SHOW HITS=NO
A6B        =FEAT/CONTACT/CIRCLE/DEFAULT,CARTESIAN,IN,LEAST_SQR
            THEO/<26.0311,8.0207,0.113>,<0,0,1>,0.128
            ACTL/<26.0311,8.0207,0.113>,<0,0,1>,0.128
            TARG/<26.0311,8.0207,0.113>,<0,0,1>
            START ANG=270,END ANG=450
            ANGLE VEC=<1,0,0>
            DIRECTION=CCW
            SHOW FEATURE PARAMETERS=NO
            SHOW CONTACT PARAMETERS=YES
              NUMHITS=5,DEPTH=0.03,PITCH=0
              SAMPLE METHOD=SAMPLE_FEATURE
              SAMPLE FEATURE=NONE
              AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              FIND HOLE=DISABLED,ONERROR=NO,READ POS=NO
            SHOW HITS=NO
A5B        =FEAT/CONTACT/CIRCLE/DEFAULT,CARTESIAN,IN,LEAST_SQR
            THEO/<26.0311,7.0507,0.113>,<0,0,1>,0.128
            ACTL/<26.0311,7.0507,0.113>,<0,0,1>,0.128
            TARG/<26.0311,7.0507,0.113>,<0,0,1>
            START ANG=270,END ANG=450
            ANGLE VEC=<1,0,0>
            DIRECTION=CCW
            SHOW FEATURE PARAMETERS=NO
            SHOW CONTACT PARAMETERS=YES
              NUMHITS=5,DEPTH=0.03,PITCH=0
              SAMPLE METHOD=SAMPLE_FEATURE
              SAMPLE FEATURE=NONE
              AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              FIND HOLE=DISABLED,ONERROR=NO,READ POS=NO
            SHOW HITS=NO
A5         =FEAT/CONTACT/CIRCLE/DEFAULT,CARTESIAN,IN,LEAST_SQR
            THEO/<25.6611,7.0507,0.113>,<0,0,1>,0.48
            ACTL/<25.6611,7.0507,0.113>,<0,0,1>,0.48
            TARG/<25.6611,7.0507,0.113>,<0,0,1>
            START ANG=24.4145,END ANG=335.5857
            ANGLE VEC=<1,0,0>
            DIRECTION=CCW
            SHOW FEATURE PARAMETERS=NO
            SHOW CONTACT PARAMETERS=YES
              NUMHITS=5,DEPTH=0.03,PITCH=0
              SAMPLE METHOD=SAMPLE_FEATURE
              SAMPLE FEATURE=NONE
              AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              FIND HOLE=DISABLED,ONERROR=NO,READ POS=NO
            SHOW HITS=NO
CIR5       =FEAT/CONTACT/CIRCLE/DEFAULT,CARTESIAN,IN,LEAST_SQR
            THEO/<27.051,7.2729,0.113>,<0,0,1>,0.0938
            ACTL/<27.051,7.2729,0.113>,<0,0,1>,0.0938
            TARG/<27.051,7.2729,0.113>,<0,0,1>
            START ANG=0,END ANG=360
            ANGLE VEC=<1,0,0>
            DIRECTION=CCW
            SHOW FEATURE PARAMETERS=NO
            SHOW CONTACT PARAMETERS=YES
              NUMHITS=5,DEPTH=0.03,PITCH=0
              SAMPLE METHOD=SAMPLE_FEATURE
              SAMPLE FEATURE=NONE
              AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              FIND HOLE=DISABLED,ONERROR=NO,READ POS=NO
            SHOW HITS=NO
B2         =FEAT/CONTACT/CIRCLE/DEFAULT,CARTESIAN,IN,LEAST_SQR
            THEO/<27.1411,5.5407,0.113>,<0,0,1>,0.2
            ACTL/<27.1411,5.5407,0.113>,<0,0,1>,0.2
            TARG/<27.1411,5.5407,0.113>,<0,0,1>
            START ANG=0,END ANG=360
            ANGLE VEC=<1,0,0>
            DIRECTION=CCW
            SHOW FEATURE PARAMETERS=NO
            SHOW CONTACT PARAMETERS=YES
              NUMHITS=5,DEPTH=0.03,PITCH=0
              SAMPLE METHOD=SAMPLE_FEATURE
              SAMPLE FEATURE=NONE
              AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              FIND HOLE=DISABLED,ONERROR=NO,READ POS=NO
            SHOW HITS=NO
A4B        =FEAT/CONTACT/CIRCLE/DEFAULT,CARTESIAN,IN,LEAST_SQR
            THEO/<26.0311,5.7057,0.113>,<0,0,1>,0.128
            ACTL/<26.0311,5.7057,0.113>,<0,0,1>,0.128
            TARG/<26.0311,5.7057,0.113>,<0,0,1>
            START ANG=270,END ANG=450
            ANGLE VEC=<1,0,0>
            DIRECTION=CCW
            SHOW FEATURE PARAMETERS=NO
            SHOW CONTACT PARAMETERS=YES
              NUMHITS=5,DEPTH=0.03,PITCH=0
              SAMPLE METHOD=SAMPLE_FEATURE
              SAMPLE FEATURE=NONE
              AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              FIND HOLE=DISABLED,ONERROR=NO,READ POS=NO
            SHOW HITS=NO
A4         =FEAT/CONTACT/CIRCLE/DEFAULT,CARTESIAN,IN,LEAST_SQR
            THEO/<25.6611,5.7057,0.113>,<0,0,1>,0.48
            ACTL/<25.6611,5.7057,0.113>,<0,0,1>,0.48
            TARG/<25.6611,5.7057,0.113>,<0,0,1>
            START ANG=24.4145,END ANG=335.5857
            ANGLE VEC=<1,0,0>
            DIRECTION=CCW
            SHOW FEATURE PARAMETERS=NO
            SHOW CONTACT PARAMETERS=YES
              NUMHITS=5,DEPTH=0.03,PITCH=0
              SAMPLE METHOD=SAMPLE_FEATURE
              SAMPLE FEATURE=NONE
              AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              FIND HOLE=DISABLED,ONERROR=NO,READ POS=NO
            SHOW HITS=NO
A3         =FEAT/CONTACT/CIRCLE/DEFAULT,CARTESIAN,IN,LEAST_SQR
            THEO/<25.6611,4.3607,0.113>,<0,0,1>,0.48
            ACTL/<25.6611,4.3607,0.113>,<0,0,1>,0.48
            TARG/<25.6611,4.3607,0.113>,<0,0,1>
            START ANG=24.4145,END ANG=335.5857
            ANGLE VEC=<1,0,0>
            DIRECTION=CCW
            SHOW FEATURE PARAMETERS=NO
            SHOW CONTACT PARAMETERS=YES
              NUMHITS=5,DEPTH=0.03,PITCH=0
              SAMPLE METHOD=SAMPLE_FEATURE
              SAMPLE FEATURE=NONE
              AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              FIND HOLE=DISABLED,ONERROR=NO,READ POS=NO
            SHOW HITS=NO
A3B        =FEAT/CONTACT/CIRCLE/DEFAULT,CARTESIAN,IN,LEAST_SQR
            THEO/<26.0311,4.3607,0.113>,<0,0,1>,0.128
            ACTL/<26.0311,4.3607,0.113>,<0,0,1>,0.128
            TARG/<26.0311,4.3607,0.113>,<0,0,1>
            START ANG=270,END ANG=450
            ANGLE VEC=<1,0,0>
            DIRECTION=CCW
            SHOW FEATURE PARAMETERS=NO
            SHOW CONTACT PARAMETERS=YES
              NUMHITS=5,DEPTH=0.03,PITCH=0
              SAMPLE METHOD=SAMPLE_FEATURE
              SAMPLE FEATURE=NONE
              AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              FIND HOLE=DISABLED,ONERROR=NO,READ POS=NO
            SHOW HITS=NO
A2B        =FEAT/CONTACT/CIRCLE/DEFAULT,CARTESIAN,IN,LEAST_SQR
            THEO/<26.0311,3.3907,0.113>,<0,0,1>,0.128
            ACTL/<26.0311,3.3907,0.113>,<0,0,1>,0.128
            TARG/<26.0311,3.3907,0.113>,<0,0,1>
            START ANG=270,END ANG=450
            ANGLE VEC=<1,0,0>
            DIRECTION=CCW
            SHOW FEATURE PARAMETERS=NO
            SHOW CONTACT PARAMETERS=YES
              NUMHITS=5,DEPTH=0.03,PITCH=0
              SAMPLE METHOD=SAMPLE_FEATURE
              SAMPLE FEATURE=NONE
              AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              FIND HOLE=DISABLED,ONERROR=NO,READ POS=NO
            SHOW HITS=NO
A2A        =FEAT/CONTACT/CIRCLE/DEFAULT,CARTESIAN,IN,LEAST_SQR
            THEO/<25.6611,3.3907,0.113>,<0,0,1>,0.48
            ACTL/<25.6611,3.3907,0.113>,<0,0,1>,0.48
            TARG/<25.6611,3.3907,0.113>,<0,0,1>
            START ANG=24.4145,END ANG=335.5857
            ANGLE VEC=<1,0,0>
            DIRECTION=CCW
            SHOW FEATURE PARAMETERS=NO
            SHOW CONTACT PARAMETERS=YES
              NUMHITS=5,DEPTH=0.03,PITCH=0
              SAMPLE METHOD=SAMPLE_FEATURE
              SAMPLE FEATURE=NONE
              AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              FIND HOLE=DISABLED,ONERROR=NO,READ POS=NO
            SHOW HITS=NO
A1A        =FEAT/CONTACT/CIRCLE/DEFAULT,CARTESIAN,IN,LEAST_SQR
            THEO/<25.6611,2.4207,0.113>,<0,0,1>,0.48
            ACTL/<25.6611,2.4207,0.113>,<0,0,1>,0.48
            TARG/<25.6611,2.4207,0.113>,<0,0,1>
            START ANG=24.4145,END ANG=335.5857
            ANGLE VEC=<1,0,0>
            DIRECTION=CCW
            SHOW FEATURE PARAMETERS=NO
            SHOW CONTACT PARAMETERS=YES
              NUMHITS=5,DEPTH=0.03,PITCH=0
              SAMPLE METHOD=SAMPLE_FEATURE
              SAMPLE FEATURE=NONE
              AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              FIND HOLE=DISABLED,ONERROR=NO,READ POS=NO
            SHOW HITS=NO
A1B        =FEAT/CONTACT/CIRCLE/DEFAULT,CARTESIAN,IN,LEAST_SQR
            THEO/<26.0311,2.4207,0.113>,<0,0,1>,0.128
            ACTL/<26.0311,2.4207,0.113>,<0,0,1>,0.128
            TARG/<26.0311,2.4207,0.113>,<0,0,1>
            START ANG=270,END ANG=450
            ANGLE VEC=<1,0,0>
            DIRECTION=CCW
            SHOW FEATURE PARAMETERS=NO
            SHOW CONTACT PARAMETERS=YES
              NUMHITS=5,DEPTH=0.03,PITCH=0
              SAMPLE METHOD=SAMPLE_FEATURE
              SAMPLE FEATURE=NONE
              AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              FIND HOLE=DISABLED,ONERROR=NO,READ POS=NO
            SHOW HITS=NO
B1         =FEAT/CONTACT/CIRCLE/DEFAULT,CARTESIAN,IN,LEAST_SQR
            THEO/<25.2111,1.7607,0.113>,<0,0,1>,0.2
            ACTL/<25.2111,1.7607,0.113>,<0,0,1>,0.2
            TARG/<25.2111,1.7607,0.113>,<0,0,1>
            START ANG=0,END ANG=360
            ANGLE VEC=<1,0,0>
            DIRECTION=CCW
            SHOW FEATURE PARAMETERS=NO
            SHOW CONTACT PARAMETERS=YES
              NUMHITS=5,DEPTH=0.03,PITCH=0
              SAMPLE METHOD=SAMPLE_FEATURE
              SAMPLE FEATURE=NONE
              AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              FIND HOLE=DISABLED,ONERROR=NO,READ POS=NO
            SHOW HITS=NO
CIR14      =FEAT/CONTACT/CIRCLE/DEFAULT,CARTESIAN,IN,LEAST_SQR
            THEO/<25.2358,0.8864,0.113>,<0,0,1>,0.4755
            ACTL/<25.2358,0.8864,0.113>,<0,0,1>,0.4755
            TARG/<25.2358,0.8864,0.113>,<0,0,1>
            START ANG=0,END ANG=360
            ANGLE VEC=<1,0,0>
            DIRECTION=CCW
            SHOW FEATURE PARAMETERS=NO
            SHOW CONTACT PARAMETERS=YES
              NUMHITS=5,DEPTH=0.03,PITCH=0
              SAMPLE METHOD=SAMPLE_FEATURE
              SAMPLE FEATURE=NONE
              AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              FIND HOLE=DISABLED,ONERROR=NO,READ POS=NO
            SHOW HITS=NO
            MOVE/POINT,NORMAL,<25.2358,0.8864,0.2425>
            TIP/T1A75B180, SHANKIJK=0, -0.9659, 0.2588, ANGLE=180
            MOVE/POINT,NORMAL,<0.4001,-0.5,2>
CIR11      =FEAT/CONTACT/CIRCLE/DEFAULT,CARTESIAN,IN,LEAST_SQR
            THEO/<0.4001,0,0.66>,<0,-1,0>,0.5
            ACTL/<0.4001,0,0.66>,<0,-1,0>,0.5
            TARG/<0.4001,0,0.66>,<0,-1,0>
            START ANG=0,END ANG=360
            ANGLE VEC=<1,0,0>
            DIRECTION=CCW
            SHOW FEATURE PARAMETERS=NO
            SHOW CONTACT PARAMETERS=YES
              NUMHITS=5,DEPTH=0.02,PITCH=0
              SAMPLE METHOD=SAMPLE_FEATURE
              SAMPLE FEATURE=NONE
              AVOIDANCE MOVE=BOTH,DISTANCE BEFORE=0.1,DISTANCE AFTER=0.1
              FIND HOLE=DISABLED,ONERROR=NO,READ POS=NO
            SHOW HITS=NO
0 Brian Enz 2 months ago in reply to Brian Enz

Here is the full code for the program.
Cancel
Vote Up 0 Vote Down

Sign in to reply

Verify Answer

Cancel
0 ArkansasBeeper 2 months ago in reply to Brian Enz

Unless you part is crooked on the machine those don't go together.

Just noticed another one?

Now at zero?

Also, it looks like in the image your trihedron is not touching your part?
Cancel
Vote Up +1 Vote Down

Sign in to reply

Verify Answer

Cancel
0 Brian Enz 2 months ago in reply to ArkansasBeeper

So essentially, I didn't properly align my part? If thats the case, would properly re-aligning it correct my errors? Or will I have to re-write the program?
Cancel
Vote Up 0 Vote Down

Sign in to reply

Verify Answer

Cancel
0 Brian Enz 2 months ago in reply to ArkansasBeeper

My ignorance is showing, but why dont those go together?
Cancel
Vote Up 0 Vote Down

Sign in to reply

Verify Answer

Cancel
0 ArkansasBeeper 2 months ago in reply to Brian Enz

You're trying to probe down a hole with a 90-degree axis at 75 degrees.
Cancel
Vote Up +1 Vote Down

Sign in to reply

Verify Answer

Cancel
0 Brian Enz 2 months ago in reply to ArkansasBeeper

I see, so changing my probe angle theoretically should fix my deviation problem?
Cancel
Vote Up 0 Vote Down

Sign in to reply

Verify Answer

Cancel
0 ArkansasBeeper 2 months ago in reply to Brian Enz

I would change the probe angle and re-create the feature that the simulation is having an issue with. But overall, I am unsure why the probe angles are not matching up to the feature vectors throughout the program. The only time I have seen that is when the part is intentionally resting at an angle relative to the machine axis.

Without seeing the drawing or knowing where the part origin is supposed to be we can't know if the alignment is correct.
Cancel
Vote Up +1 Vote Down

Sign in to reply

Verify Answer

Cancel
