Contact analysis problem

Hi there!! I asking a big help. I doing my master thesis with MSC Patran/Nastran and it consists in a non linear analysis because there are contact and plastic deformation. About contact I had any problem, i have been working for 1 month for that!!! I have already read the manual about this argument and I understand so much but i have problem yet! I make screenshots for each step with a very easy example for understand well this analysis. I attached the powerpoint with screenshots!!!!

Thank you in advance

Attached Files (1)

MSC COMMUNITY.pdf

0 Hrishikesh Phadke over 5 years ago
Cancel
Vote Up 0 Vote Down

Sign in to reply

Verify Answer

Cancel
0 s243752 over 5 years ago

Ok perfect thank you, and about body pair is necessarly??
Cancel
Vote Up 0 Vote Down

Sign in to reply

Verify Answer

Cancel
0 Hrishikesh Phadke over 5 years ago

Body pair is not neccessary. I prefer using contact table since there are just 2 bodies.
Cancel
Vote Up 0 Vote Down

Sign in to reply

Verify Answer

Cancel
0 s243752 over 5 years ago

Ok perfect!! Thank you for all!! I can try to put these feature in my thesis' model!! If I will have any problem, probably I will make another topic!! sorry ahahah Thank you!!!
Cancel
Vote Up 0 Vote Down

Sign in to reply

Verify Answer

Cancel
0 s243752 over 5 years ago

Sorry @Hrishikesh Phadke I have another problem, i can try to make another example with sphere and cylinder. I managed to get the deformed but I have problem with penetration. I have two question:

1) How can I delete penetration? I would like the sphere every tangent to cylinder

2) Why I can't have isomesh in this solids?

Thank you

Attached Files (1)

contatto_sfera.db
Cancel
Vote Up 0 Vote Down

Sign in to reply

Verify Answer

Cancel
0 Kiranraj Shetty over 5 years ago

Hi,

Find the modified model, contact is working fine. db is in 2018 Patran version, I have attached the bdf as well.

Regards,

Kiran

Attached Files (1)

contact_1.zip
Cancel
Vote Up 0 Vote Down

Sign in to reply

Verify Answer

Cancel
0 s243752 over 5 years ago

I can't open this file, maybe for the version of Patran, I have this message:

There is a problem attempting to open the database you have specified.

Database Name: C:\Users\Riccardo\Desktop\contatto_sfera.db

Product Version: 2017.0.1 23.0.493986

Database Engine Version: pdb.1.0.C14

Schema Version: PATRAN_3_19

Last Used On Platform: Windows 64-bit

Acknowledge this message for possible further information about why this database cannot be opened.

Is there any way to open this file??
Cancel
Vote Up 0 Vote Down

Sign in to reply

Verify Answer

Cancel
0 Kiranraj Shetty over 5 years ago

As mentioned earlier, the db is in 2018 version, you need 2018 or later Patran versions to open the file. However you can import the bdf in older Patran, or submit it to Nastran solver.
Cancel
Vote Up 0 Vote Down

Sign in to reply

Verify Answer

Cancel
0 s243752 over 5 years ago

Yeah for that I think the problem is about the version. I can try with your bdf and I look that the sphere doesn't work with cylinder, or better there isn't any contact between them.
Cancel
Vote Up 0 Vote Down

Sign in to reply

Verify Answer

Cancel
0 s243752 over 5 years ago

I can try to do a very easier example with a circle and a rectangle, all in 2D for analyze better the contact. And as you can see, the penetration about the circle and the other shell it is evident. With your example I don't understand because the sphere doesn't went aginst cylinder.

Attached Files (1)

Contatto_2D.zip
